Kohler 20EKOZD

TP-6953 7/19162 Section 9 Component Testing and Adjustment
Model Engine Governor Type
Fault Warning and Shutdown Tests
Overspeed Overcrank Engine Sensors (A) External Sensors (B)
13EKOZD/11EFKOZD
Kohler
KDI
Mechanical
Yes Yes Yes Yes
14EKOZD/12EFKOZD
15EKOZD/13EFKOZD
16EKOZD/13.5EFKOZD
20EKOZD/16.5EFKOZD
20EKOZD/17.5EFKOZD
21EKOZD/18EFKOZD
21EKOZD/17EFKOZD
23EKOZD/19.5EFKOZD
23EKOZD/20EFKOZD
24EKOZD/20.5EFKOZD
32EKOZD/28EFKOZD
Electronic
40EKOZD/35EFKOZD
Figure 9 -15 Feasibility of Fault Warning and Shutdown Tests
Model Engine Freq.
High Coolant
Temperature
Shutdown, C(F)
High Coolant
Temperature
Warning, C(F)
Low Oil Pressure
Shutdown,
kPa (psi)
Low Oil Pressure
Warning,
kPa (psi)
13EKOZD/11EFKOZD
Kohler
KDI
50/60 110 (230)
107 (225)
83 (12) 138 (20)
14EKOZD/12EFKOZD
15EKOZD/13EFKOZD
16EKOZD/13.5EFKOZD
20EKOZD/16.5EFKOZD
20EKOZD/17.5EFKOZD
21EKOZD/18EFKOZD
21EKOZD/17EFKOZD
23EKOZD/19.5EFKOZD
23EKOZD/20EFKOZD
24EKOZD/20.5EFKOZD
32EKOZD/28EFKOZD
105 (221)
40EKOZD/35EFKOZD
Figure 9 -16 Factory Shutdown and Warning Setpoints
Model Engine
High Coolant Temp.
Fault
Low Coolant Temp.
Fault
Low Oil Pressure
Fault
Test Connections Test Connections Test Connections
13EKOZD/11EFKOZD
Kohler
KDI
1 Lead 5 1 Lead 5
1 Lead 7
14EKOZD/12EFKOZD
15EKOZD/13EFKOZD
3
A- Lead 5
B- Lead N
3
A- Lead 5
B- Lead N
16EKOZD/13.5EFKOZD
20EKOZD/16.5EFKOZD
20EKOZD/17.5EFKOZD
21EKOZD/18EFKOZD
21EKOZD/17EFKOZD
23EKOZD/19.5EFKOZD
23EKOZD/20EFKOZD
24EKOZD/20.5EFKOZD
32EKOZD/28EFKOZD
Consult the Engine Service Manual
40EKOZD/35EFKOZD
Figure 9 -17 Fault Warning and Shutdown Te st Method for Decision-Makerr 3500 Controller
