Inhibit Time Delay. The inhibit time delay is the time
period following crank disconnect during which the
generator set stabilizes and the controller does not
detect a fault or status event. Select the desired inhibit
time delay from 0 to 60 seconds. A setting of 0 means
the warning is monitored continuously, even if not
running.
TIme Delay (Shutdown or Warning). The time delay
follows the inhibit time delay. The time delay is the time
period between when the controller first detects a fault
or status event and the controller warning or shutdown
lamp illuminates. The delay prevents nuisance alarms.
Select the desired time delay from 0 to 60 seconds.
Section 2.8.3 and Section 2.8.4 contain warnings and
faults with ranges and time delays including items that
do not have user adjustments.
Note: The engine ECM may limit the crank cycle even if
the controller is set to a longer time period.
2.8.3 Warning Parameter Default
Setting
Figure 2-20 lists default settings for common warnings.
Fault
Condition
Sensing
Mechanism
Warning
Condition
When
Active
Inhibit
Time
Time
Delay
Display
Cleared On
Low oil
pressure
pre-alarm
Pressure sender 20 psi Running Crank disconnect
+30sec.
0sec. Warning
removal,
generator off
High coolant
temperature
Temperature sender
225_ F
ON Crank disconnect
+30sec.
0sec. Warning
removal,
generator off
Low cranking
voltage
Battery analog input Vbat < 60% of
nominal
Cranking Cranking. 3sec. Next good
crank or
system reset
Low battery
voltage (12V)
Battery analog input <11V Continuous,
not cranking
0, Always 60 sec. Warning
removed
High battery
voltage (12V)
Battery analog input >16V Continuous,
not cranking
0, Always 60 sec. Warning
removed
Low battery
voltage (24V)
Battery analog input <22V Continuous,
not cranking
0, Always 60 sec. Warning
removed
High battery
voltage (24V)
Battery analog input >30V Continuous,
not cranking
0, Always 60 sec. Warning
removed
Battery charger
fault
Digital input from
charger
Input closed Continuous 0, Always 1sec. Warning
removed
Low fuel Digital input from
fuel switch
Input closed Continuous 0, Always 10 sec. Warning
removed
Low coolant
temperature
Digital input Input closed Continuous 0, Always 10 sec. Warning
removed
Not in auto Mode switch Mode not in auto Continuous 0, Always 0sec. Warning
removed
Figure 2 -20 Warning Parameter Default Table
