Kohler 20EKOZD

TP-6953 7/1984 Section 2 Operation
SiteTecht Parameter
Write
Access
Units
Decision-Maker r 3500
User Interface
Notes
Analog Resistive Input Low Shutdown Delay Always s Low Shutdown Delay: ##s Thetimethattheinput
must be within its
shutdown operating
range before a shutdown
protective is indicated
Analog Resistive Input High Shutdown Delay Always s High Shutdown Delay: ##s Thetimethattheinput
must be within its
shutdown operating
range before a shutdown
protective is indicated
Analog Resistive Input Low Warning Limit Always Low Warning Limit: The limit that the input
must drop below to enter
its low warning operating
range
Analog Resistive Input Critically Low Warning Limit Always The limit that the input
must drop below to enter
its low warning operating
range
Analog Resistive Input Low Shutdown Limit Always Low Shutdown Limit: The limit that the input
must drop below to enter
its low shutdown
operating range
Analog Resistive Input High Warning Limit Alway s High Warning Limit: The limit that the input
must exceed to enter its
high warning operating
range
Analog Resistive Input Critically High Warning Limit Always The limit that the input
must exceed to enter its
high warning operating
range
Analog Resistive Input High Shutdown Limit Alway s High Shutdown Limit: The limit that the input
must exceed to enter its
high shutdown operating
range
Analog Resistive Input Deadband Always A percentage of the
parameter value, which
defines the hysteresis for
the protective ranges
Analog Resistive Input Relative Upper Range Limit Always Indicates the limit in raw
form when the input will
be considered shorted
high
Analog Resistive Input Relative Lower Range Limit Always Indicates the limit in raw
form when the input will
be considered shorted
low
Analog Resistive Input Relative Range Limit Deadband Always Specifies how much the
raw value needs to
change by before no
longer considered
shorted
Analog Resistive Input Relative Range High Limit Inhibit
Time
Always s Specifies what the inhibit
time should be when the
input is considered
shorted high
Analog Resistive Input Relative Range Low Limit Inhibit
Time
Always s Specifies what the inhibit
time should be when the
input is considered
shorted low
Analog Resistive Input Relative Range Limit Delay Always s Specifies what the
debounce time is on the
input after the inhibit time
is met
Analog Resistive Input Description Always Description: A user-defined
description of this IO
