TP-6805 8/15 41Section 4 Controller
SiteTech Group Notes [
Default
Setting
Adjustment
Range *
UnitsParameter
Generator Metering
Generator Apparent Power L1 VA Read Only N/A N/A
Generator Apparent Power L2 VA Read Only N/A N/A
Generator Apparent Power L3 VA Read Only N/A N/A
Generator Total Apparent Power VA Read Only N/A N/A
Generator Reactive Power L1 VAR Read Only N/A N/A
Generator Reactive Power L2 VAR Read Only N/A N/A
Generator Reactive Power L3 VAR Read Only N/A N/A
Generator Total Reactive Power VAR Read Only N/A N/A
Generator True Power L1 W Read Only N/A N/A
Generator True Power L2 W Read Only N/A N/A
Generator True Power L3 W Read Only N/A 3-phase
Generator True Total Power W Read Only N/A N/A
Generator True Percent Of Rated
Power
% Read Only N/A N/A
Generator Voltage L1-L2 V Read Only N/A
Generator Voltage L2-L3 V Read Only N/A 3-phase
Generator Voltage L3-L1 V Read Only N/A 3-phase
Generator Voltage Average Line
To Line
V Read Only N/A
Generator Current L1 A Read Only N/A N/A
Generator Current L2 A Read Only N/A N/A
Generator Current L3 A Read Only N/A 3-phase
Generator Current Average A Read Only N/A
Generator Frequency Hz Read Only N/A
Genset Info
Genset Model Number Select Dropdown list:
14KW
20KW
Factory-
set per
unit. See
Section
4.4.2
Genset Serial Number 0--20 characters
Alternator Part Number 0--20 characters N/A
Genset Controller Serial Number 1--10 characters
Engine Part Number 0--20 characters N/A
Engine Model Number CH-740 (14) or
CH-1000 (20)
(Selected
automatically with
genset model)
Engine Serial Number 0--10 characters N/A
Genset State N/A Read Only N/A
Genset Run Time
Genset Controller Clock Time Read Only N/A
Genset Controller Total Operation
Time
h Read Only N/A
Engine Total Run Time h Read Only N/A
Engine Total Run Time Loaded h Read Only N/A N/A
Engine Total Number Of Starts Read Only N/A
Genset Date Time Of Last
Maintenance
Read Only
(See Section 2.3,
Resetting the
Maintenance Timer)
1/1/01
12:00:00
AM
* Read Only = Not adjustable
[ Notes indicate applicability to genset model and accessories. N/A = Not applicable to these generator s ets.
] See TT-1584 for more information about digital inputs and outputs.
