10
TT-1651 4/17a
Sound Shield Parts List
Kits: GM93548-KP1, GM93548-KP2, GM93548-KP3, and GM93548-KP4
Qty. Description Common Parts
Unique Parts
GM93548-KP1 GM93548-KP2 GM93548-KP3 GM93548-KP4
4 Corner, sound shield GM74137
4 Bracket, sound shield corner
(1 x 1.6 in.)
GM74790
10 Bracket, sound shield panel
mounting (1.1 x 1.8 in.)
GM77222
1 Bracket, sound shield mounting GM93616
2 Rail, sound shield GM89784-1
4 Rail, sound shield GM89784-2
1 Door, front (engine end) GM93562
1 Panel, RH (service side, controller) GM89881
1 Duct, alternator air intake GM89976
1 Bracket, panel mounting GM82181
1 Duct, alternator air intake GM90676
1 Panel, customer connection GM93558
1 Door, rear (alternator end) GM93560
1 Bracket, mounting GM93411
1 Tube, front mixing GM92557-2
1 Lead, ground LK-0616-1715
9 Washer, plain (#5 screw size) M125A-05-80
8 Nut, hex (8 mm) M6923-08-80
9 Screw, pan head machine
(M5 x 20 mm)
M7985A-05020-20
18 Screw, hex cap (M8 x 20 mm) M933-08020-SS
10 Washer, plain (0.344 ID x 0.75 in.
OD)
X-25-139
3 Nut, wing (1/4--20) X-276-9
1 Hose X-312-49
2 Clamp, hose (0.69/1.25 in.) X-426-12
1 Cable, battery (positive, red) X-545-259
1 Cable, battery (negative, black) X-545-241
1 Hose, coolant X-373-30
2 Bushing X-634-28
1 Clamp, insulated (1.06 in.) X-672-32
1 U-channel X-6047-14
4 Screw, Phillips hex crimptite X-6216-1
27 Bolt, carriage X-6224-20
1 Decal, caution GM93648
1 Harness, extension GM96427
1 Washer, plain M125A-06-80
1 Nut, hex (6mm) M6923-06-80
1 Screw, hex cap (M6 x 20 mm) M933-06020-60
2 Washer, lock (.262 in. ID x.743 in.
OD)
X-22-12
27 Nut, flange spiralock (5/16-18) X-6210-7
1 Door, RH (service side) GM89867 GM90504 GM90513 GM93638
1 Door, LH (non service side) GM89877 GM90507 GM90516 GM93640
1 Roof GM89898 GM90510 GM90519 GM93642
2 Rail, sound shield GM89784-3 GM89784-4 GM89784-5 GM89784-9
2 Bracket, mounting (side) GM89786 GM90529 GM90530 GM93637
