58 TP-7044 6/23
Generator Information Menu
(Continued)
Generator Information Menu (Continued)
Generator Information Menu (Continued)
◊ kW RATING: ####kW
◊ kVA RATING: #####kVA
◊ RATED CURRENT: ###A
◊ BATTERY VOLTAGE:
##VDC*
◊ POWER ECM: ON/OFF*
◊ ENGINE START DELAY:
##s*
◊ STARTING AID DELAY:
##s*
◊ CRANK ON DELAY: ##s*
◊ CRANK PAUSE DELAY:
##s*
◊ ENGINE WARMED UP:
###°F
◊ ENGINE COOLED DOWN:
###°F
◊ COOLDOWN DELAY: ##s*
◊ COOLDOWN OVERRIDE:
ON/OFF*
◊ FUEL TYPE: (NATURAL
GAS/LP/GASOLINE/
DIESEL/ UNKNOWN)*
◊ CRANK CYCLES LIMIT:##*
◊ NFPA DEFAULTS:
ON/OFF*
◊ EMERGENCY
BATTLEMODE: ON/OFF*
◊ POWER UP IN AUTO:
ON/OFF*
◊ NOT IN AUTO WARN
ENABLE: ON/OFF*
◊ AUX FAULT DELAY: ##s*
◊ AUX FAULT INHIBIT
DELAY: ##s*
o PROTECTION
CONFIGURATION
◊ OVERVOLTAGE: ###%*
◊ OVERVOLTAGE: ###.#V
◊ OVERVOLTAGE DELAY:
##s*
◊ UNDERVOLTAGE: ##%*
◊ UNDERVOLTAGE: ##.#V
◊ UNDERVOLTAGE DELAY:
##s*
◊ OVERFREQUENCY: ##%*
◊ OVERFREQUENCY:
##.#Hz
◊ UNDERFREQUENCY:
##%*
◊ UNDERFREQUENCY:
##.#Hz
◊ OVERSPEED: ##.#%*
◊ OVERSPEED: ##.#Hz
◊ OVERSPEED: ####RPM
◊ LOW BATTERY VOLTAGE:
###%*
◊ LOW BATTERY VOLTAGE:
##.#VDC
◊ HIGH BATTERY
VOLTAGE: ###%*
◊ HIGH BATTERY
VOLTAGE: ##.#VDC
o BATT X BASIC CONFIG
Note:
This menu option does not
apply to marine generator sets.
◊ BATTERY TOPOLOGY:
(DEFAULT/
VRLA/ AGM/GEL/NiCd*
◊ CHARGER SYSTEM
VOLTAGE: 12VDC/24VDC
◊ AUTO EQUALIZE ENABLED:
ON/OFF*
◊ TEMP COMPENSATION
ENABLED: ON/OFF*
◊ ABSORPTION TERMINATION:
#.##A
(+/- 0.05)*
◊ BULK VOLTAGE: ##.##VDC
(+/- 0.05)*
◊ ABSORPTION VOLTAGE:
##.##VDC (+/- 0.05) *
◊ FLOAT VOLTAGE: ##.##VDC
(+/- 0.05)*
◊ MANUAL EQUALIZE ACTIVE:
YES/NO*
◊ CUSTOM PROFILE ENABLED:
ON/OFF*
◊ TEMP COMPENSATION
SLOPE: ##mV/C*
◊ EQUALIZE VOLTAGE:
##.##VDC (+/- 0.05)*
◊ MAX ABSORPTION TIME:
###MIN*
◊ MAX BULK TIME: ###MIN*
◊ BULK STATE RETURN: ##.##V
(+/- 0.05)*
• Voltage Regulation
o AVG GEN VOLTAGE L-L: ###.#V
o VOLTAGE ADJUST: ###.#V*
o TARGET VOLTAGE: ###.#V
o L1-L2 VOLTS: ###.#V
o L2-L3 VOLTS: ###.#V
o L3-L1 VOLTS: ###.#V
o GEN FREQUENCY: ##.#Hz
o V/Hz SETPOINT: ##.#Hz*
o V/Hz SLOPE: ##%/Hz*
o VOLT DROOP AT 100% kVAR:
##.#%*
o VOLTAGE GAIN ADJUST: ###*
o START UP RAMP RATE: ###.#%/s*
o RESET REG. DEFAULTS:YES/NO*
• Paralleling Operation
o PARALLELING SETUP
◊ DEAD BUS LEVEL: ##.#%*
◊ VOLTAGE OK PICKUP: ##.#%*
◊ VOLTAGE OK DROPOUT:
##.#%*
◊ FREQUENCY OK PICKUP:
##.#Hz*
◊ FREQUENCY OK DROPOUT:
##.#Hz*
◊ VOLTS-Hz OK DELAY: ##.#s*
◊ FIRST ON DELAY: ##.#s*
◊ FAIL TO OPEN DELAY: ##s*
◊ FAIL TO CLOSE DELAY: ##s*
◊ RECLOSE DELAY: ##.#s*
◊ MAX CLOSE ATTEMPTS: ###*
◊ CB CRNT FAULT LIMIT:
###.#%*
◊ CB CRNT FAULT DELAY:
##.#s*
◊ CB PHASE FAULT LIMIT:
##.#_*
◊ CB PHASE FAULT DELAY:
##.#s*
◊ kW RAMP RATE: ##.#%/s*
◊ kW DISCONNECT LEVEL:
##.#%*
◊ TRIMS ENABLE: ON/OFF*
◊ LOAD ENABLE: ON/OFF*
◊ SYSTEM LOAD CONTROL:
ON/OFF*
◊ SYSTEM SYNC CONTROL:
ON/OFF*
◊ STAND ALONE MODE:
ON/OFF*
◊ SYNC MODE IN AUTO:
(INVALID/OFF/PASSIVE/
CHECK/ ACTIVE/DEAD
FIELD)*
◊ SYNC MODE IN RUN:
(INVALID/OFF/PASSIVE/
CHECK/ ACTIVE/DEAD
FIELD)*
o SYNCHRONIZING SETUP
◊ SYNC MODE IN RUN:
(INVALID/OFF/PASSIVE/
CHECK/ ACTIVE/DEAD
FIELD)*
◊ SYNC MODE IN AUTO:
(INVALID/OFF/PASSIVE/
CHECK/ ACTIVE/DEAD
FIELD)*
◊ CONNECTED TO BUS:
TRUE/FALSE
◊ VOLTS-Hz OK: TRUE/FALSE
◊ IN SYNC: TRUE/FALSE
◊ VOLTAGE MATCHED:
TRUE/FALSE
◊ VOLTAGE MATCH WINDOW:
##.#%*
◊ AVG BUS VOLTAGE L-L:
###.#V
◊ AVG GEN VOLTAGE L-L:
###.#V
◊ VOLTAGE MATCH P GAIN:
##.##*
◊ VOLTAGE MATCH I GAIN:
##.##*
◊ VOLTAGE MATCH D GAIN:
##.##*
◊ VOLTAGE BIAS: ###.##
◊ FREQUENCY MATCHED:
TRUE/FALSE
◊ FREQUENCY WINDOW:
#.#Hz*
◊ BUS FREQUENCY: ##.##Hz
◊ GEN FREQUENCY: ##.##Hz
◊ FREQ MATCH P GAIN:##.##*
◊ FREQ MATCH I GAIN: ##.##*
◊ FREQ MATCH D GAIN:##.##*
◊ SPEED BIAS: ###.##
◊ PHASE MATCHED:
TRUE/FALSE
◊ PHASE MATCH WINDOW:
##.#°*
◊ PHASE DIFFERENCE: ###.#°
◊ PHASE MATCH P GAIN:
##.##*
◊ PHASE MATCH I GAIN:
##.##*
◊ PHASE MATCH D GAIN:
##.##*
◊ SPEED BIAS: ###.##
◊ DWELL TIME: ##.#s*
◊ DWELL TIME REMAINING:
##.#s
◊ FAIL TO SYNC TIME: ####s*
◊ SYNC TIME REMAINING:
####s
* User-Defined (changeable) Menu Displays. Use SiteTech™ software to change other settings including User-Defined Menu Displays.
