Kohler 28EFKOZD User Manual

TP-7044 6/23 59
Generator Information Menu
(Continued)
Generator Information Menu (Continued)
Controller Configuration Menu
◊ BUS PHASE ROTATION:
DISABLED/A-B-C/C-B-A
◊ GEN PHASE ROTATION:
DISABLED/A-B-C/C-B-A
o SHARING SETUP
◊ BUS % OF RATED kW:
###.##%
◊ GEN % OF RATED kW:
###.##%
◊ kW SHARING P GAIN:
##.##*
◊ kW SHARING I GAIN:
##.##*
◊ kW SHARING D GAIN:
##.##*
◊ SPEED BIAS: ###.##
◊ SYSTEM FREQUENCY:
##.#Hz
◊ GEN FREQUENCY: ##.#Hz
◊ FREQ TRIM P GAIN: ##.##*
◊ FREQ TRIM I GAIN: ##.##*
◊ FREQ TRIM D GAIN:
##.##*
◊ SPEED BIAS: ###.##
◊ FREQ DROOP AT 100%
kW: ##.#%*
◊ BUS % OF RATED kVAR:
###.##%
◊ GEN % OF RATED kVAR:
###.##%
◊ kVAR SHARING P GAIN:
##.##*
◊ kVAR SHARING I GAIN:
##.##*
◊ kVAR SHARING D GAIN:
##.##*
◊ VOLTAGE BIAS: ###.##
◊ SYSTEM VOLTAGE L-L:
###.#V
◊ AVG GEN VOLTAGE L-L:
###.#V
◊ VOLT TRIM P GAIN: ##.##*
◊ VOLT TRIM I GAIN: ##.##*
◊ VOLT TRIM D GAIN: ##.##*
◊ VOLTAGE BIAS: ###.##
◊ VOLT DROOP AT 100%
kVAR: ##.#%*
o PROTECTIVE RELAY SETUP
◊ OVER POWER TRIP:
###.#%*
◊ OVER POWER DELAY:
##.#s*
◊ REVERSE POWER TRIP:
###.#%*
◊ REVERSE POWER
DELAY: ##.#s*
◊ OVER VOLTAGE TRIP:
###.#%*
◊ OVER VOLTAGE DELAY:
##.#s*
◊ UNDER VOLTAGE TRIP:
###.#%*
◊ UNDER VOLTAGE DELAY:
##.#s*
◊ OVER FREQ TRIP:
###.#%*
◊ OVER FREQ DELAY:
##.#s*
◊ UNDER FREQ TRIP:
###.#%*
◊ UNDER FREQ DELAY: ##.#s*
◊ REVERSE VAR TRIP: ###.#%*
◊ REVERSE VAR DELAY: ##.#s*
◊ OVER CURRENT TRIP: ###.#%*
◊ OVER CURRENT DELAY: ##.#s*
◊ TRIP TO SHTDWN DELAY:
#####s*
o GENERATOR MANAGEMENT
◊ GEN MANAGEMENT MODE:
◊ (INVALID/MANUAL FIXED/RUN
TIME/FUEL LEVEL)*
◊ GEN MANAGEMENT: ON/OFF*
◊ GEN MANAGEMENT ORDER: #*
will revert to previous setting in
run time or fuel level mode.
◊ START CAPACITY: ###.#%*
◊ START DELAY: ####s*
◊ STOP CAPACITY: ###.#%*
◊ STOP DELAY: ####s*
◊ TOTAL BUS CAPACITY: #####kW
◊ BUS TOTAL POWER: #####kW
◊ START kW: #####kW
◊ STOP kW: #####kW
◊ START ACCUMULATOR: #####
◊ STOP ACCUMULATOR: #####
◊ RUN TIME THRESHOLD: ###.#hrs*
◊ only if in Run Time Management
◊ TOTAL RUN TIME: #######.#hrs
◊ FUEL LEVEL THRESHOLD: ##.#%*
only if in Fuel Level
Management
◊ FUEL LEVEL: ###.#%
◊ STABLE DELAY: ####s*
◊ MINIMUM GENS ONLINE: ##*
◊ MIN LOADS ADDED: ##*
◊ STOPPED BY GEN MGMT:
◊ TRUE/FALSE
o LOAD CONTROL
◊ GEN MAX % CAP: ###.#%*
◊ GEN OVERLOAD %: ###.#%*
• Controller Configuration
o LANGUAGE: English*
o UNITS: Metric/English*
o TIME FORMAT: Hr 12/Hr 24*
o DATE FORMAT: Month Date
Year/
o Date Month Year*
o DATE: ##/##/####*
o TIME: ##:## XM*
o CONTRAST: ###*
o ALARM SILENCE:
ALWAYS/AUTO ONLY*
• Communication Setup
o MODBUS BAUD RATE:
OFF/9600 b/s/
o 19200 b/s/38400 b/s/57600 b/s/
o 115200 b/s*
o MODBUS ADDRESS: ##*
o PGEN BAUD RATE: OFF/9600
b/s/
o 19200 b/s/38400 b/s/57600 b/s/
o 115200 b/s
o PGEN NODE ID: ##
o PGEN NODES ONLINE: ##
o PGEN NODES OFFLINE: ##
• Calibration
When the line is highlighted, hold the
knob down to enable the calibration
capability.
o GEN L1-L0 VOLTS: ###.#V*
o GEN L2-L0 VOLTS: ###.#V*
o GEN L3-L0 VOLTS: ###.#V*
o GEN L1-L2 VOLTS: ###.#V*
o GEN L2-L3 VOLTS: ###.#V*
o GEN L3-L1 VOLTS: ###.#V*
o GEN L1 CURRENT: ###.#A*
o GEN L2 CURRENT: ###.#A*
o GEN L3 CURRENT: ###.#A*
o BUS L1-L2 VOLTS: ###.#V*
o BUS L2-L3 VOLTS: ###.#V*
o BUS L3-L1 VOLTS: ###.#V*
o RESET GEN VOLT METER:
YES/NO*
o RESET GEN AMP METER:
YES/NO*
o RESET BUS VOLT METER:
YES/NO*
o RESET ALL METERS: YES/NO*
* User-Defined (changeable) Menu Displays. Use SiteTech™ software to change other settings including User-Defined Menu Displays.
