Specifi cations
1162 690 01 Rev. C KohlerEngines.com
5
Measure 11 mm (0.433 in.) above bottom of piston skirt at right angles to piston pin.
Wear Limits
CH940 CH960 CH980 CH1000
Governor Cross Shaft O.D.
New
Max. Wear Limit
7.963/8.000 mm (0.3135/0.3149 in.)
7.936 mm (0.3124 in.)
Governor Gear Shaft-to-Governor Gear Running Clearance 0.070/0.160 mm (0.0027/0.0063 in.)
Governor Gear Shaft O.D.
New
Max. Wear Limit
5.990/6.000 mm (0.2358/0.2362 in.)
5.977 mm (0.2353 in.)
Ignition
Spark Plug Gap 0.76 mm (0.030 in.)
Ignition Module Air Gap 0.28/0.33 mm (0.011/0.013 in.)
Main Bearing I.D. (crankcase/closure plate)
New (installed)
Max. Wear Limit
45.040/45.145 mm (1.773/1.777 in.)
45.158 mm
Piston, Piston Rings, and Piston Pin
Piston-to-Piston Pin Running Clearance 0.006/0.018 mm (0.0002/0.0007 in.)
Piston Pin Bore I.D.
New
Max. Wear Limit
19.006/17.013 mm (0.7482/0.7485 in.)
19.025 mm (0.7490 in.)
Piston Pin O.D.
New
Max. Wear Limit
18.995/19.000 mm (0.7478/0.7480 in.)
18.994 mm (0.7478 in.)
Top Compression Ring-to-Groove Side Clearance 0.04/0.08 mm (0.0015/0.0031 in.)
Middle Compression Ring-to-Groove Side Clearance 0.04/0.08 mm (0.0015/0.0031 in.)
Oil Control Ring-to-Groove Side Clearance 0.03/0.19 mm (0.0011/0.0074 in.)
Top and Center Compression Ring End Gap
New
Max. Wear Limit
0.30/0.55 mm (0.011/0.021 in.)
0.94 mm (0.037 in.)
Piston Thrust Face O.D.
5
New
Max. Wear Limit
89.953/89.967 mm (3.5414/3.5420 in.)
89.925 mm (3.540 in.)
Piston Thrust Face-to-Cylinder Bore
5
Running Clearance
New 0.033/0.72 mm (0.0013/0.0028 in.)
Valves and Valve Lifters
Hydraulic Valve Lift er to Crankcase Running Clearance 0.012/0.050 mm (0.0004/0.0019 in.)
Intake Valve Stem-to-Valve Guide Running Clearance 0.038/0.076 mm (0.0015/0.0030 in.)
Exhaust Valve Stem-to-Valve Guide Running Clearance 0.050/0.088 mm (0.0020/0.0035 in.)
Intake Valve Guide I.D.
New
Max. Wear Limit
7.038/7.058 mm (0.2771/0.2779 in.)
7.135 mm (0.2809 in.)
Exhaust Valve Guide I.D.
New
Max. Wear Limit
7.038/7.058 mm (0.2771/0.2779 in.)
7.159 mm (0.2819 in.)
Valve Guide Reamer Size
Standard
0.25 mm O.S.
7.048 mm (0.2775 in.)
7.298 mm (0.2873 in.)
Nominal Valve Face Angle 45°
