Disassembly
4762 690 01 Rev. C KohlerEngines.com
WARNING
Before working on engine or equipment, disable engine as
follows: 1) Disconnect spark plug lead(s). 2) Disconnect
negative (–) battery cable from battery.
Accidental Starts can cause severe injury or
death.
Disconnect and ground spark plug lead(s)
before servicing.
A
B
U
C
D
E
F
G
I
H
J
L
M
N
K
L
I
H
O
S
R
V
P
P
Q
T
U
V
U
Heavy-Duty Air Cleaner
Low-Profi le
Air Cleaner
A Oil Filter B Oil Filter Nipple C Oil Filter Cup D Valve Spring
E Cup Spring F Valve G Oil Filter Housing H Valley Baffl e
I Outer Cylinder Baffl e J Electric Starter K Backing Shroud L Cylinder Shroud
M Blower Housing N Guard O Oil Sentry
™
P O-ring
Q Pin R Fitting S Oil Filter Adapter T Oil Cooler
U Hose V Hose Clamp
