Electrical System
42 62 690 01 Rev. CKohlerEngines.com
Troubleshooting Guide
NOTE: Always zero ohmmeter on each scale before testing to ensure accurate readings. Voltage tests should be
made with engine running at 3600 RPM - no load. Battery must be good and fully charged.
15/20/25 Amp Battery Charging Systems
When problems occur in keeping battery charged or battery charges at too high a rate, problem can usually be found
somewhere in charging system or with battery.
Problem Test Conclusion
No Charge
to Battery
*NOTE: Turn on lights, if 60 watts or more. Or
place a 2.5 ohm, 100 watt resistor
across battery terminals.
1. Trace B+ lead from recti er-regulator to key
switch, or other accessible connection.
Disconnect it from switch or connection.
Connect an ammeter from loose end of B+
lead to positive terminal of battery. Connect
DC voltmeter from loose end of B+ lead to
negative terminal of battery. With engine
running at 3600 RPM, read voltage on
voltmeter.
If voltage is 13.8 volts or more, place a
minimum load of 5 amps* on battery to
reduce voltage. Observe ammeter.
1. If voltage is 13.8-14.7 and charge rate
increases when load is applied, charging
system is OK and battery was fully charged.
If voltage is less than 13.8 or charge rate
does not increase when load is applied,
check regulator-recti er ground. Adequate
ground is required for regulator-recti er to
operate. If ground path is good, test stator
(tests 2 and 3).
2. Remove connector from recti er-regulator.
With engine running at 3600 RPM, measure
AC voltage across stator leads using an AC
voltmeter.
2. If voltage is 28 volts or more, stator is OK.
Recti er-regulator is faulty. Replace
recti er-regulator.
If voltage is less than 28 volts, stator is
probably faulty and should be replaced. Test
stator further using an ohmmeter (test 3).
3 a. With engine stopped, measure
resistance across stator leads using an
ohmmeter.
b. With engine stopped, measure
resistance from each stator lead to
ground using an ohmmeter.
3 a. If resistance is 0.064/0.2 ohms, stator is
OK.
If resistance is in nity ohms, stator is
open. Replace stator.
b. If resistance is in nity ohms (no
continuity), stator is OK (not shorted to
ground).
If resistance (or continuity) is measured,
stator leads are shorted to ground.
Replace stator.
Battery
Continuously
Charges at
High Rate
4. Perform same test as Step 1 above. 4. If voltage is 14.7 volts or less charging
system is OK. Battery is unable to hold a
charge. Service battery or replace as
necessary.
If voltage is more than 14.7 volts, recti er-
regulator is faulty. Replace recti er-
regulator.
