8.4
Section 8
Disassembly
Figure 8-11. Removing Air Cleaner Base.
Remove Throttle Control Panel
1. Disconnect the thro le control cable.
2. Remove the 4 hex fl ange screws securing the
thro le control panel and remove the panel from
the blower housing. See Figure 8-12.
2. Disconnect the thro le linkage spring. Remove
the thro le linkage bushing and thro le linkage
from the governor lever. See Figure 8-13.
Figure 8-14. Disconnecting Throttle Linkage Spring.
5. Loosen the hex fl ange nut and remove the
governor lever from the cross sha . See Figure 8-14.
Figure 8-15. Removing Governor Lever.
Remove Lift Fuel Pump and Fuel Pump
Module
Figure 8-13. Disconnect Governor Spring.
Figure 8-12. Remove Throttle Control Panel.
Remove External Governor Controls
1. Disconnect the governor spring a aching the
governor lever to the thro le actuator lever. See
Figure 8-12.
Throttle
Linkage
Spring
Throttle
Linkage
Throttle
Linkage
Bushing
Remove Hex Flange
Screws
WARNING
Explosive Fuel can cause fi res
and severe burns.
Do not fi ll the fuel tank while the
engine is hot or running.
Explosive Fuel!
Gasoline is extremely fl ammable and its vapors can explode
if ignited. Store gasoline only in approved containers, in well
ventilated, unoccupied buildings, away from sparks or fl ames.
Do not fi ll the fuel tank while the engine is hot or running,
since spilled fuel could ignite if it comes in contact with hot
parts or sparks from ignition. Do not start the engine near
spilled fuel. Never use gasoline as a cleaning agent.
