Kohler Command PRO ECH749 Service Manual

8.7
Section 8
Disassembly
8
Figure 8-24. Disconnecting Intake Air Temperature
Sensor.
3. Disconnect the thro le position sensor connector.
See Figure 8-25.
Figure 8-25. Disconnecting Throttle Position
Sensor.
4. Disconnect the vent hose from the thro le body.
See Figure 8-26.
Figure 8-26. Disconnecting Vent Hose.
5. Slide the thro le body off the intake manifold.
Remove Electronic Control Unit (ECU)
1. Remove the two hex fl ange screws securing the
ECU to the bracket. See Figure 8-27.
Figure 8-27. Removing ECU Fasteners.
2. Disconnect the Black and Grey electrical
connectors from the ECU. See Figure 8-28.
Figure 8-28. Disconnecting the ECU Electrical
Connectors.
Remove Electronic Control Unit Bracket
and Electric Starter Motor
1. Disconnect the leads from the starter.
2. Remove the two hex fl ange screws. See Figure 8-29.
Figure 8-29. Removing Electric Starter Motor.
Mounting
Bolts

Kohler Command PRO ECH749 Specifications

General

Fuel System	Carburetor
Starter	Electric
Governor Type	Mechanical
Lubrication System	Full Pressure
Fuel Type	Gasoline
Crankshaft Orientation	Horizontal
Bore	3.27 in (83 mm)
Cooling System	Air
Oil Type	SAE 10W-30
Spark Plug Gap	0.030 in (0.76 mm)
Valve Clearance - Intake	0.004 - 0.006 in (0.10 - 0.15 mm)
Crankshaft Type	Varies by model
Crankshaft Thread Size	Varies by model
Crankshaft Length	Varies by model
Crankshaft Diameter	Varies by model
Type	Overhead Valve (OHV)
