33
Starter System
18 690 01 Rev. B KohlerEngines.com
2. Unscrew center screw and lift off drive plate.
3. Note positions of pawls and pawl springs before
removing. Remove parts from pulley.
4. Install pawl springs and pawls into pawl slots of
pulley. All parts must by dry.
5. Position drive plate over pawls, aligning actuating
slots in place with raised sections on each drive
pawl. Torque center screw to 5-6 N·m (44-54 in. lb.).
6. Remove clamp and pull starter rope out part way to
check operation of pawls.
Install Starter
1. Install retractable starter onto blower housing leaving
screws slightly loose.
2. Pull starter handle out until pawls engage in drive
cup. Hold handle in this position and tighten screws
securely.
