Kohler Courage SH265 Service Manual

8
Specifi cations
KohlerEngines.com 18 690 01 Rev. B
CLEARANCE SPECIFICATIONS
3
SH265
Camshaft
End Play 0.025/0.602 mm (0.0010/0.0237 in.)
Running Clearance 0.016/0.052 mm (0.0006/0.0020 in.)
Bore I.D.
New
Max. Wear Limit
14.000/14.018 mm (0.5512/0.5519 in.)
14.048 mm (0.5531 in.)
Connecting Rod
Crankpin End I.D. @ 21°C (70°F)
New
Max. Wear Limit
30.021/30.026 mm (1.1819/1.1821 in.)
30.08 mm (1.184 in.)
Connecting Rod-to-Crankpin Running Clearance
New
Max. Wear Limit
0.041/0.051 mm (0.002/0.002 in.)
0.12 mm (0.005 in.)
Connecting Rod-to-Crankpin Side Clearance
New
Max. Wear Limit
0.58/0.60 mm (0.023/0.024 in.)
1.10 mm (0.043 in.)
Connecting Rod-to-Piston Pin Running Clearance 0.01/0.027 mm (0.0004/0.0011 in.)
Piston Pin End I.D. @ 21°C (70°F)
New
Max. Wear Limit
18.010/18.015 mm (0.709/0.709 in.)
18.08 mm (0.712 in.)
Crankcase
Governor Cross Shaft Bore I.D.
New
Max. Wear Limit
6.000/6.018 mm (0.2362/0.2369 in.)
6.037 mm (0.2377 in.)
Crankshaft
End Play (free) 0.025/0.703 mm (0.0010/0.028 in.)
Ball Bearing 0.003/0.25 mm (0.0001/0.0010 in.)
Bore (in crankcase)
New, without Main Bearing 51.961/51.991 mm (2.0457/2.0469 in.)
Bore (in closure plate)
New, without Main Bearing 51.961/51.991 mm (2.0457/2.0469 in.)
Flywheel End Main Bearing Journal O.D.
O.D.-New
O.D.-Max. Wear Limit
Max. Taper
Max. Out-of-Round
24.975/24.989 mm (0.9833/0.9838 in.)
24.95 mm (0.9823 in.)
0.025 mm (0.0010 in.)
0.025 mm (0.0010 in.)
Closure Plate End Main Bearing Journal O.D.
O.D.-New
O.D.-Max. Wear Limit
Max. Taper
Max. Out-of-Round
24.975/24.989 mm (0.9833/0.9838 in.)
24.95 mm (0.9823 in.)
0.025 mm (0.0010 in.)
0.025 mm (0.0010 in.)
Connecting Rod Journal O.D.
O.D.-New
O.D.-Max. Wear Limit
Max. Taper
Max. Out-of-Round
Width
29.975/29.985 mm (1.1801/1.1805 in.)
29.920 mm (1.1779 in.)
0.025 mm (0.0010 in.)
0.025 mm (0.0010 in.)
25.02/25.08 mm (0.9850/0.9874 in.)
Runout (either end) 0.025 mm (0.0010 in.)
Main Bearing I.D. (Crankcase/Closure Plate)
New (installed) 24.994/25.000 mm (0.9840/0.9842 in.)
3
Values are in Metric units. Values in parentheses are English equivalents.
5
Lubricate threads with engine oil prior to assembly.

Kohler Courage SH265 Specifications

General

Compression Ratio	8.5:1
Lubrication	Splash
Governor Type	Mechanical
Air Cleaner	Dual element
Starter Type	Recoil
Engine Type	OHV
Power	6.5 hp
Fuel Capacity	1.0 gal. (3.8 L)
Oil Capacity	0.6 liters
Ignition System	Electronic
Valve Configuration	Overhead Valve (OHV)
Dry Weight	16 kg (35 lbs)
