7
Specifi cations
18 690 01 Rev. B KohlerEngines.com
TORQUE SPECIFICATIONS
3,5
SH265
Flywheel
Retaining Nut 74 N·m (655 in. lb.)
Fuel Tank
Mounting Nut 24 N·m (212 in. lb.)
Mounting Screw 24 N·m (212 in. lb.)
Inlet Fitting 1.5 N·m (13.3 in. lb.)
Governor
Arm Nut 10 N·m (88.5 in. lb.)
Throttle Control Lever Nut 4.5-6 N·m (40-53 in. lb.)
Ignition
Spark Plug 27 N·m (20 ft. lb.)
Module Fastener 8 N·m (70.8 in. lb.)
Module Screw 10 N·m (88.5 in. lb.)
Oil Sentry
™
Module Screw 8 N·m (70.8 in. lb.)
Muffl er
M8 Exhaust Screw 24 N·m (212 in. lb.)
M6 Muffl er Shield Screw 8 N·m (70.8 in. lb.)
M4 Muffl er Shield Screw 2 N·m (17.7 in. lb.)
M5 Spark Arrestor Screw 3.5 N·m (31 in. lb.)
Retractable Starter
Cover Screw 5.4 N·m (47.8 in. lb.)
Screw 10 N·m (88.5 in. lb.)
Rocker Arm
Stud 13.6 N·m (120 in. lb.)
Pivot Jam Nut 10 N·m (88.5 in. lb.)
Valve Cover
Fastener 8 N·m (70.8 in. lb.)
3
Values are in Metric units. Values in parentheses are English equivalents.
5
Lubricate threads with engine oil prior to assembly.
