158 Section 8 Component Testing and Adjustment TP-6356 4/12
Model Engine
Governor
Type
High Coolant Temp.
Fault Shutdown
Low Oil Pressure
Fault Shutdown
Test Connections Test Connections
Gas
25--150REZG GM
ECM
Control
-- Not Available -- Not Available
25--150RZG/RZGB
GM
Electronic 1 Lead 34 1 Lead 13
80/100REZGB/RZGB
ECM
Control
-- Not Available -- Not Available
180--400REZX
Doosan
ECM
Control
-- Not Available -- Not Available
180--400RZX
200--275RZDB DDC Gas
ECM
Control
1 Lead 34 1 Lead 13
Diesel
20REOZJ
John Deere
Mech./Elect.
1 Lead 34 1 Lead 13
20/30REOZJC ECM Control
20--230REOZJB Mech./Elect.
40--60REOZJC
ECM Control
3
A--Lead 461
B--Lead 414
4
A/1--Lead 414
B/2--Lead 467
C/4--Lead 416
80--180REOZJC 1 Lead 34 1 Lead 13
80--275REOZJD
3
A--Lead 461
B--Lead 414
4
A/1--Lead 414
B/2--Lead 467
C/4--Lead 416
80--275REOZJE
200REOZJC
275/300REOZV
Volvo ECM Control
1 Lead 34
2
A/1--Lead 4 BLK
B/2--Lead 1 RED
C/4--Lead 2
GRY/ORG
350/400REOZVC
450/500REOZVB
5
A--Lead 1 BLK
B--Lead 2 BRN/ORG
A/1--Lead 4 BLK
B/2--Lead 1 RED
C/4--Lead 2
BLU/ORG
550/600REOZV
200REOZPB DDC S40 ECM Control 1 Lead 34 1 Lead 13
230--300REOZDB
DD/MTU
Series 60
ECM Control 3
A--Lead 452 BLK
B--Lead 133 PNK
4
A/1--Lead 452 BLK
B/2--Lead 530 BRN
C/4--Lead 416 GRY
230--450REOZDD
350/400REOZDC
450REOZDB
650--2000REOZDB
DD/MTU ECM Control 6
Harness Marker B6
A-- Pin 1
B-- Pin 2
4
Harness Marker B5
A/1--Pin 1
B/2--Pin 2
C/4--Pin 4
650--2250REOZDC
700--1000REOZDD
600--2000REOZM
Mitsubishi
Electronic
1 Lead 34 1 Lead 13
600--2000REOZMB
ECM
Control
BLK Black; BLU Blue; BRN Brown; GRY Gray; GRN Green; ORG Orange; PNK Pink; WHT White
Figure 8-63 Fault Shutdown Test Method for Decision-Makerr 3+
