Section 7 Decision-Makerr 6000 ControllerTP-6356 4/12
Status Event
or Fault
User-Defined
Settings
Time
Delay
(sec.)
Inhibit
Time
Delay
(sec.)
Default
Selection
Range Setting
Relay
Driver
Output
(RDO)
Digital Display
Refer
to
Menu
kW Overload
(see Load Shed)
—
Load Shed Common 10 COMMON
LOAD SHED
RDO-25 Not adjustable
Load Shed
kW Overload
8, 10 LOAD SHED
KW OVER
80%--120% 100% of kW
rating with
5 sec. delay
0.3 2--10
Load Shed
Underfrequency
10 LOAD SHED
UNDER
FREQUENCY
Fixed 59 Hz
(60 Hz)
49 Hz
(50 Hz)
0.3 5
Locked Rotor
Shutdown
10 LOCKED
ROTOR
Fixed 5 Not adjustable
Loss of ECM
Communication
(ECM only)
10 LOSS OF ECM
COMM
Fixed 0 4 Not adjustable
Loss of Field (see SD
Loss of Field)
—
Low Battery Voltage 10 LOW BATTERY
VOL TAGE
RDO-11
(lead 62)
10--12.5 V (12 V)
20--25 V (24 V)
12 V (12 V)
24 V (24 V)
0 10
Low Coolant Level
D14
(with LCL switch) [
9, 10 LOW
COOLANT L VL
D14
RDO-8 Fixed 30 sec.
inhibit,
5 sec. delay
Not adjustable
Low Coolant
Temperature (Analog
Input or ECM)
10 LOW
COOLANT
TEMP
RDO-7
(lead 35)
Fixed 0 sec.
inhibit,
0 sec. delay
Not adjustable
Low Coolant
Temperature D03 [
9, 10 LOW
COOLANT
TEMP D03
Fixed 0 sec.
inhibit,
0 sec. delay
Not adjustable
Low Coolant
Temperature
Shutdown *
10 LOW COOL
TEMP SDWN
Not adjustable
Low Fuel (Level or
Pressure) Shutdown
D09
9,10 LOW FUEL
SHUTDWN
D09
0 sec.
inhibit,
0 sec. delay
0--60 0--60
Low Fuel (Level or
Pressure) Warning
(D02 or ECM) [
9, 10 LOW FUEL
WARNING D02
RDO-5 Fixed 0 sec.
inhibit,
0 sec. delay
Not adjustable
(Low) Oil Pressure
Shutdown (Analog
Input or ECM)
10 OIL
PRESSURE
SHUTDOWN
(lead 38) Fixed 30 5 Not adjustable
(Low) Oil Pressure
Warning (Analog
Input or ECM)
10 OIL
PRESSURE
WARNING
RDO-9
(lead 41)
Fixed 30 0 Not adjustable
Maintenance
Reminder
10 MAINTENANCE
DUE
RDO-13 0--4095 hours 0= No
Reminder
Master (Switch) Not
In Auto (Generator
Set Switch)
10 MASTER NOT
IN AUTO
RDO-23
(lead 80)
Not adjustable
Master Switch Error 10 MASTER
SWITCH
ERROR
Not adjustable
Master Switch to Off 10 MASTER
SWITCH TO
OFF
Not adjustable
Master Switch Open 10 MASTER
SWITCH OPEN
Not adjustable
Missing PGEN Node 10 MISSING
PGEN NODE
RDO-26 Fixed 5 Not adjustable
NFPA 110 Fault 10 NFPA 110
FAULT
RDO-10
(lead 32)
Not adjustable
No Coolant
Temperature Signal
10 NO COOL
TEMP SIGNAL
Fixed 30 4 Not adjustable
* DD/MTU engine with MDEC/ADEC
[ NFPA applications
] 3x (times) energize time shown in Menu 17
