TP-6953 7/1950 Section 2 Operation
Menu Summary List (Legend: D First level submenu, d second level submenu, Z third level submenu)
d CHARGER TEMP: ###_F
d REDUCED OUTPUT ACTIVE: YES/NO
d TEMP COMPENSATION ACTIVE: YES/NO
d SOFTWARE VER.: XXXXXXXXXXXX
D Overview
d
GENERATOR STATUS
Z AVG GEN VOLTAGE L-L: ###V
Z AVG CURRENT: # ##A
Z GEN FREQUENCY: ##.#Hz
d ENGINE STATUS
Z COOLANT TEMPERATURE: ###_F
Z OIL PRESSURE
: ###PSI
Z GEN BATTERY VOLTAGE: ##.#V
d SYSTEM STATUS
Z FUEL PRESSURE: ###PSI
Z TOTAL POWER: ####kW
Z TOTAL RUN TIME: #####.#hrs
D Paralleling Metering
d
CONNECTED TO BUS: TRUE/FALSE
d AVG BUS VOLTAGE L-L: ###.#V
d AVG GEN VOLTAGE L-L: ###.#V
d BUS FREQUENCY: ##.##Hz
d GEN FREQUENCY : ##.##Hz
d BUS TOTAL POWER: #####.#kW
d BUS % OF RATED kW: ###%
d BUS % OF RATED kVAR: ###%
Generator Information
Menu
D Generator Information
d
TOTAL RUN TIME: #####.#hrs
d HOURS LOADED: #####hrs
d HOURS UNLOADED: #####hrs
d kW HOURS: #####kWh
d OPERATING HOURS: ######hrs
d TOTAL # OF STARTS: ########
d LAST MAINTENANCE: ##/##/####
d OP HRS SINCE MAINT: ####hrs
d STARTS SINCE MAINT: ###
d ENG HRS SINCE MAINT: ####hrs
d LOADED SINCE MAINT: ####hrs
d UNLOADED SINCE MAINT: ####hrs
d kW HRS SINCE MAINT: ####kWh
d RESET MAINT RECORDS: YES/NO*
d LAST START: ##/##/####
d LAST RUN LENGTH: ####hrs
d CTRL SERIAL #: XXXXXXXXX
d SOFTWARE VER.: XXXXXXXXX
d ECM SERIAL #: XXXXXXXXX
d GENSET MODEL #: XXXXXXXXX
d GENSET SPEC. #: XXXXXXXXX
d GENSET SERIAL #: XXXXXXXXX
d ALT. PART #: XXXXXXXXX
d ENGINE PART #: XXXXXXXXX
d ENGINE MODEL #: XXXXXXXXX
d ENGINE SERIAL #: XXXXXXXXX
D Event History
d
GENERATOR EVENT HISTORY
##/##/#### (Date) ##:##.##XX (Time)
DEVICE EVENT: ###
STATUS/FAULT/NOTICE/WARNING
EVENT X OF Y
d ENGINE EVENT LOG
SPN: ####
FMI: ##
OCCURRENCE COUNT: ###
EVENT X OF Y
Metering
Menu
Metering
Menu (Continued)
D Generator Metering
d
L1-L2 VOLTS: ###V
d L2-L3 VOLTS: ###V
d L3-L1 VOLTS: ###V
d AVG GEN VOLTAGE L -L: ###V
d GEN FREQUENCY: ##.#Hz
d L1-L0 VOLTS: ###V
d L2-L0 VOLTS: ###V
d L3-L0 VOLTS: ###V
d AVG GEN VOLTAGE L -N: ###V
d GEN FREQUENCY: ##.#Hz
d L1 CURRENT: ###A
d L2 CURRENT: ###A
d L3 CURRENT: ###A
d AVG CURRENT: ###A
d GEN FREQUENCY: ##.#Hz
d L1 POWER: ####W
d L2 POWER: ####W
d L3 POWER: ####W
d TOTAL POWER: ####.#kW
d GEN % OF RATED kW: ###%
d L1 REACTIVE POWER: ####VAR
d L2 REACTIVE POWER: ####VAR
d L3 REACTIVE POWER: ####VAR
d TOT AL REACTIVE POWER: ####V AR
d L1 APPARENT POWER: ####VA
d L2 APPARENT POWER: ####VA
d L3 APPARENT POWER: ####VA
d TOTAL APPARENT PWR: ####VA
d GEN % OF RATED kVA: ###%
d L1 PF: #.##
d L2 PF: #.##
d L3 PF: #.##
d TOTAL PF: #.##
d GEN PHASE ROTATION: ###
D Engine Metering
d
ENGINE SPEED: ####RPM
d ECM BATTERY VOLTAGE: ##.#VDC
d GEN BATTERY VOLTAGE: ##.#VDC
d GENSET CONTROLLER TEMP: ###_F
d OIL PRESSURE: ###PSI
d OIL TEMPERATURE: ###_F
d COOLANT TEMPERATURE: ###_F
d COOLANT PRESSURE: ###PSI
d FUEL LEVEL: ###%
d FUEL PRESSURE: ###PSI
d FUEL TEMPERATURE: ###_F
d FUEL RATE: ###GAL/h
(shown if available from ECM)
d FUEL USED LAST RUN: ###GAL
(shown if available from ECM)
d CRANKCASE PRESSURE: ###PSI
d INTAKE AIR PRESSURE: ###PSI
d INTAKE AIR TEMP: ###_F
D Battery X Meter
Note: This menu option does not apply
to marine generator sets.
d ST ATUS: (IDLING/ST ANDBY/
CHARGING/ BA T T F AIL/CHRGR F AIL/
NOT A VAILABLE)
d OUTPUT VOLTAGE: ##.#VDC
d OUTPUT CURRENT: ##.#A
d CHARGER STATE: IDLE/BULK/
ABSORB/FLOAT/EQUAL/REFRESH/
RECOVER/NA
Generator Information
Menu (Continued)
D Configuration
d
GENERATOR CONFIGURATION
Z OPERATING MODE: (STANDBY/PRIME)
Z APPLICATION TYPE: (NONE/MARINE/
MOBILE/STANDBY/PRIME)
Z SYSTEM VOLTAGE L-L: ###V*
Z SYSTEM FREQUENCY: ##.#Hz*
Z SYSTEM PHASE: (SINGLE/SINGLE
DOG/THREE-WYE/THREE- DELTA)*
Z RATED ENGINE SPEED: ####RPM
Z ENGINE SPEED ADJUSTMENT: *
Z ADJUSTED ENGINE RUN SPEED:
####RPM
Z kW RATING: ####kW
Z kVA RATING: #####kVA
Z RATED CURRENT: ###A
Z BATTERY VOLTAGE: ##VDC*
Z POWER ECM: ON/OFF*
Z ENGINE START DELAY: ##s*
Z STARTING AID DELAY: ##s*
Z CRANK ON DELAY: ##s*
Z CRANK PAUSE DELAY: ##s*
Z ENGINE WARMED UP: ###
_F
Z ENGINE COOLED DOWN: ###
_F
Z COOLDOWN DELAY: ##s*
Z COOLDOWN OVERRIDE: ON/OFF*
Z FUEL TYPE: (NATURAL GAS/LP/
GASOLINE/DIESEL/UNKNOWN)*
Z CRANK CYCLES LIMIT: ##*
Z NFPA DEFAULTS: ON/OFF*
Z EMERGENCY BA TTL EMODE: ON/OFF*
Z POWER UP IN AUTO: ON/OFF*
Z NOT IN AUTO WARN ENABLE: ON/OFF
Z AUX FAULT DELAY: ##s*
Z AUX FAULT INHIBIT DELAY: ##s*
d PROTECTION CONFIGURATION
Z OVERVOLTAGE: ###%*
Z OVERVOLTAGE: ###.#V
Z OVERVOLTAGE DELAY: ##s*
Z UNDERVOLTAGE: ##%*
Z UNDERVOLTAGE: ##.#V
Z UNDERVOLTAGE DELAY: ##s*
Z OVERFREQUENCY: ##%*
Z OVERFREQUENCY: ##.#Hz
Z UNDERFREQUENCY: ##%*
Z UNDERFREQUENCY: ##.#Hz
Z OVERSPEED: ##.#%*
Z OVERSPEED: ##.#Hz
Z OVERSPEED: ####RPM
Z LOW BATTERY VOLTAGE: ###%*
Z LOW BATTERY VOLTAGE: ##.#VDC
Z HIGH BATTERY VOLTAGE: ###%*
Z HIGH BATTERY VOLTAGE: ##.#VDC
d BATT X BASIC CONFIG
Note: This menu option does not apply to
marine generator sets.
Z BATTERY TOPOLOGY: (DEFAULT/
VRLA/ AGM/GEL/NiCd*
Z CHARGER SYSTEM VOL TAGE:
12VDC/24VDC*
Z AUTO EQUALIZE ENABLED: ON/OFF*
Z TEMP COMPENSA TION ENABLED:
ON/OFF*
Z ABSORPTION TERMINATION: #.##A
(+/- 0.05)*
Z BULK VOL TAGE: ##.##VDC (+/- 0.05)*
Z ABSORPTION VOLTAGE: ##.##VDC
(+/- 0.05) *
Z FLOAT VOL TAGE: ##.##VDC (+/- 0.05)*
Z
MANUAL EQUALIZE ACTIVE: YES/NO*
Z CUSTO M PROFILE ENABLED: ON/OFF*
Z TEMP COMPENSATION SLOPE: ##mV/C*
Z EQUALIZE VOLTAGE: ##.##VDC
(+/- 0.05)*
Z MAX ABSORPTION TIME: ###MIN*
Z MAX BULK TIME: ###MIN*
Z BULK ST ATE RETURN: ##.##V (+/- 0.05)*
* User-Defined (changeable) Menu Displays. Use SiteTecht software to change other settings including User-Defined Menu Displays.
