TP-6953 7/1952 Section 2 Operation
Active Events
Menu
Rotate the dial to view Active Events:
Warnings
Shutdowns
Statuses
Notices
Press the OFF button to return to the
main menu.
I/O
Menu
D Resistive Input
Analog Input 0:1
Analog Input 0:2
Analog Input 0:3
Analog Input 0:4
Analog Input 0:5
Analog Input 0:6
d
DESCRIPTION: (function by default
unless modified via SiteTech)
d MEASUREMENT: ###.#Ohms
d EVENT: *
d INPUT ENABLED: ON/OFF*
d SENSOR TYPE: *
d LOW PROTECTIVE INHIBIT: ##s*
d LOW WARNING: ON/OFF*
d LOW WARNING LIMIT: *
d LOW WARNING DELAY: ##s*
d LOW SHUTDOWN: ON/OFF*
d LOW SHUTDOWN LIMIT: *
d LOW SHUTDOWN DELAY: ##s*
d HIGH PROTECTIVE INHIBIT: ##s*
d HIGH WARNING: ON/OFF*
d HIGH WARNING LIMIT: *
d HIGH WARNING DELAY: ##s*
d HIGH SHUTDOWN: ON/OFF*
d HIGH SHUTDOWN LIMIT: *
d HIGH SHUTDOWN DELAY: ##s*
I/O
Menu (Continued)
D Digital Input
Digital Input 0:1
Digital Input 0:2
Digital Input 0:3
Digital Input 0:4
Digital Input 0:5
Digital Input 0:6
d
DESCRIPTION: (function by default
unless modified via SiteTech)
d STATUS: ACTIVE/INACTIVE
d FUNCTION: *
d EVENT: *
d LOGIC: ACTIVE ON/ACTIVE OFF *
d ENABLED: ON/OFF*
d INHIBIT TIME: ##s*
d DELAY TIME: ##s*
D Digital Output
Digital Output 0:1
Digital Output 0:2
Digital Output 0:3
Digital Output 0:4
Digital Output 1:1
(Note: Only displayed if the 15-Relay
Dry Contact Kit is installed.)
...
d
DESCRIPTION: (function by default
unless modified via SiteTech)
d STATUS: ACTIVE/INACTIVE
d FUNCTION: *
d EVENT: *
d LOGIC: ACTIVE ON/ACTIVE OFF*
* User-Defined (changeable) Menu Displays. Use SiteTecht software to change other settings including User-Defined Menu Displays.
