TT-1379 5/16 5
GM100955-
Connects to the
remote digital gauge
connector.
Connects to the
remote extension
harness connector.
Figure 10 Remote Gauge Harness GM100955
(Included with Kit GM100956-KP1)
GM100990-
25 ft. Extension Harness Kit GM91774-KP1
50 ft. Extension Harness Kit GM91774-KP2
100 ft. Extension Harness Kit GM91774-KP3
Figure 11 Remote Extension Harness Kits
(For Use With Kit GM100956-KP1)
GM100997
25 ft. Extension Harness Kit GM92053-KP1
50 ft. Extension Harness Kit GM92053-KP2
100 ft. Extension Harness Kit GM92053-KP3
Figure 12 Remote Extension Harness Kits
(For Use With Kit GM100956-KP1)
GM100996-
Y Harness Kit GM92054-KP1
Figure 13 Y Harness Kit
(For Use With Kit GM100956-KP1)
GM92060-A
Figure 14 Remote System Diagram For Kit GM100956-KP1
