Installation
Run cold and hot water through the shower outlet to flush out
dirt and debris.
Insert the screen washer into the end of the inlet of the
handshower.
Thread the hose collar onto the inlet.
Thread the hose nut to the shower outlet.
Wrench tighten the hose nut to the shower outlet. Do not
overtighten.
Turn on the shower valve (not shown).
Check for leaks at each end of the handshower hose and the inlet
of the handshower. Make any adjustments as needed.
Turn off the shower valve.
Hose Collar
Screen Washer
Handshower
Hose
Hose Nut
Handshower
Inlet
To shower outlet.
Kohler Co. 3 1085896-2-D
