2
15
A A
Fig. 2.1
α ≤ 15° α ≤ 15°
SAFETY INFORMATION
EN
• Fully tighten the tank cap each time after refuelling. Do not
fill the tank right to the top but leave an adequate space for
the fuel to expand.
• To start the engine follow the specific instructions provided
in the engine and/or machine operating manual. Do not
use auxiliary starting devices not originally installed on the
machine (e.g. Startpilot).
• Before starting, remove any tools that were used to service
the engine and/or machine. Make sure that all guards have
been refitted.
• Do not mix fuel with elements such as oil or kerosene. Failure
to comply with this prohibition will cause the non-operation of
the catalyst and non-observance of the emissions declared
by KOHLER.
• Pay attention to the temperature of the oil filter when the filter
itself is replaced.
• Only check, top up and change the coolant fluid when the
engine is off and reached the ambient temperature. Coolant
fluid is polluting, it must therefore be disposed of in the correct
way.
• Do not use air and water jets at high pressures on cables,
connectors and injectors.
Important
• Only use the eyebolts A installed by KOHLER to move the
engine (Fig. 2.1).
• The angle between each lifting chain and the eyebolts shall
not exceed 15° inwards.
• The correct tightening of the lifting screws is 25Nm.
• Do not interpose spacers or washers between the eyebolts
and engine head.
• Provided that the above requirements are met, if the lifting
eyebolts are subject to permanent deformation (inwards), all
subsequent lifting operations must be performed in order to
prevent them from bending in the opposite direction.
UM KDI 1903TCR_2504TCR _ cod. ED0053029490 - 2° ed_rev. 01
