Kohler KDI-2504TCR

To Next Page

To Previous Page

ENEN

GENERAL INFORMATION

Manufacturer and motor identication data

Peak

rpm

Engine serial number

Approval data and

"EC" directives

Engine type

Engine

version

Manufacturer identication

The nameplate motor identication is nd side A or side B.

SIDE VIEW A SIDE VIEW B

UM KDI 1903TCR_2504TCR _ cod. ED0053029490 - 2° ed_rev. 01
