32
2
_07
Fig. 2.10
OUT IN
2
3
4
1
5
ED0053029590
TECHNICAL INFORMATION
2.9.6 Fuel lter
The fuel lter is situated on the crankcase of the engine or it
may be assembled on the frame of the vehicle.
POS. COMPONENTS DESCRIPTION
1 Fuel lter support
2 Fuel system lling button
3 Cartridge
4 Water in fuel sensor
5 Wing nut, lter drainage
Cartridge characteristics
DESCRIPTION VALUE
Filtering surface 2,300 cm
2
Degree of ltration 5 µm
Max operating pressure 2.0 Bar
Max ow rate 190 litres/hour
Tab. 2.16
Tab. 2.17
