Specications
32 690 03 Rev. N KohlerEngines.com
Engine Dimensions with Low Prole or High Performance Air Cleaner-Valve Cover Side
A
B
C
D
E
F
A 87.6 mm (3.45 in.) B
Engine Mounting
Surface
C 152.9 mm (6.02 in.) D 4.4 mm (0.17 in.)
E Mounting Hole "A" F 39.8 mm (1.57 in.)
