Kohler RDC2 Installation

TP-7091 4/23 57
Figure 52 Breather Tube Heater
Figure 53 Oil Heater
Heating element
Label
Thermostat
120 VAC female connector
(connect to oil heater)
120 VAC plug
GM110893-CMP
Pin Connector
Label
female connector (connect
to oil heater)
Thermostat
Heating element
14 and 20 kW Models
26 kW Models
Heating element
Heating probe
Label
120 VAC male connector (connect to breather tube heater)
GM110895-CMP
14 and 20 kW Models
26 kW Models
Label
Pin Connector
Heating element
Heating probe
Oil drain
Oil drain
