Kolver EDU 2AE/TOP - Serial Print Data Format

Manual EDU 2AE/TOP and EDU 2AE/TOP/TA Rev. 3 Page 23
CORRECT SCREWS MESSAGES ON DISPLAY
On the status bar it will display “Screw OK”.
A correct screwing has been performed,
reaching the pre-set torque value.
On the status bar it will display “Angle OK”.
A correct screwing has been performed,
reaching the pre-set angle.
On the status bar it will display “Runtime OK”.
A correct screwing has been performed,
reaching the pre-set runtime.
On the status bar it will display “Reverse torque OK”
A correct screwing has been performed,
reaching the pre-set reverse torque
value.
SERIAL PRINT:
Every control unit is supplied with a 9 pin male connector (connection pin: PIN 2 = TX, PIN 5 = GND) and
a mini USB connector. You can print on PC (for example through Hyper Terminal programs) or printer ( for
example our printer PRNTR1) the results of each screwing. The transmission characteristics are the
following: 9600 (bits per second), 8 (data bits), n (no parity), 1 (bits stop 1).
The print string is the following:
BARCODE
RESULT
PROGRAM
NUMBER
MODEL
TORQUE
%
SPEED
JOINT
SCREW
SEQUENCE
STAGE
TORQUE
ANGLE
DATE
HOUR
NOTICE
BC: Barcode = it begins with “BC:” and it’s followed by the code of the scanned product.
Result = screwing result: correct or incorrect.
OK = the torque has been correctly reached, all the selected parameters are satisfied and the control
unit will give out a beep sound of 0.5 sec.
NOK = the torque has been reached during ramp time or brake time (see error table). In this
case, the unit will give out 2 beepsounds and the red led will light up.
PR: Program number = it indicates the running program.
Model = Model of screwdriver you’re using.
T%: Torque% = percentage of the set torque level.
S: Speed = preset speed value.
J: Joint = type of preset joint (H= hard o S=soft).
Screw: Number of screws = number of tightened screws/total number of screws.
Seq: Sequence stage = it indicates the stage of the sequence.
T: Torque = torque value.
