IO. GENERAL VIEW
10.1 GENERAL VIEW OF MACHINE
If directions
are indicated in
this
section, they refer to the directions
shown by the arrows in the diagram below.
A
Pe
RIGHT
FRONT
This illustration shows the D32E-1
