SEN01979-01 01 Specification
10 PC138US, USLC-8
List of weights 1
k This weight table is prepared for your reference when handling or transporting the components.
Unit: kg
Machine model
PC138US-8
Standard specification Blade specification
Serial No. 20001 and up
Engine assembly (excl. coolant and oil) 458 458
• Engine (excl. coolant and oil) 332 332
• Engine mount 18.1 18.1
•PTO 5.5 5.5
• Hydraulic pump 102 102
• • Filter (for KA specification) (6 x 2) (6 x 2)
Cooling assembly (excl. coolant and oil) 82.2 82.2
• Radiator (excl. coolant) 7.9 7.9
• Oil cooler (excl. oil) 10.2 10.2
• Aftercooler 8.1 8.1
• Fuel cooler (excl. fuel) 0.7 0.7
Revolving frame 1,400 1,400
Operator cab 375 375
Operator seat 38 38
Fuel cooler (excl. fuel) 90.6 90.6
Hydraulic tank (excl. hydraulic oil) 79.5 79.5
Control valve 95 99
Counterweight 3,240 2,855
Added counterweight 500 500
Swing motor (incl. brake valve) 20 20
Swing circle 152.6 152.6
Swing machinery 71.6 71.6
Center swivel joint 28.6 43.6
Track frame assembly (excl. track shoe) 2,300 2,410
• Track frame 1,305 1,415
• Idler assembly 79 x 2 79 x 2
• Recoil spring assembly 69 x 2 69 x 2
• Carrier roller 16.5 x 2 16.5 x 2
• Track roller 22 x 14 22 x 14
• Travel motor (with final drive) 145 x 2 145 x 2
• Sprocket 33.1 x 2 33.1 x 2
Track shoe assembly
• Triple grouser shoe (500 mm) 755 x 2 755 x 2
• Triple grouser shoe (600 mm) 840 x 2 840 x 2
• Triple grouser shoe (700 mm) 930 x 2 930 x 2
• Triple grouser shoe (750 mm) 975 x 2 975 x 2
• Single grouser shoe (510 mm) 860 x 2 860 x 2
• City pad shoe (500 mm) 750 x 2 750 x 2
• City pad shoe (600 mm) — —
• Road liner (500 mm) 810 x 2 810 x 2
