Troubleshooting by failure code
Failure code [D1EMKA] (Disconnection of parking brake interlock relay)
WA900-3E0
Troubleshooting by failure code
40-9
Failure code [D1EMKA] (Disconnection of parking brake interlock relay)
40-9
Action level Failure code
Failure Open circuit in parking brake interlock relay
E03 D1EMKA
Detail of failure
q Controller detects open circuit while driving parking brake interlock relay.
Action of con-
troller
q Stops driving solenoid and buzzer until its power supply is turned off.
Problem on
machine
q Ladder does not move when switch is operated.
q Parking brake can be released (parking brake interlock does not function) even if ladder is not
stored in position.
Related infor-
mation
q Ladder can be moved to storage and boarding positions by using emergency release valve.
q Output signal to parking brake interlock relay can be checked with monitoring function.
Code: 40990 "D-OUT-0" (ON: 1, OFF: 0)
q Even when parking brake interlock relay has open circuit, ladder RAISE and LOWER operations
are possible if this failure code disappears and interlock relay is not activated. (When ladder is
stored in position with starting switch at OFF position, controller does not drive interlock relay even
if parking brake releasing operation is performed.)
q If interlock relay is activated when parking brake emergency release connector in fuse box is dis-
connected (emergency release state), this failure code appears.
No. Cause Procedure, measuring location, criteria and remarks
1
Open circuit in wiring harness
(wire breakage or defective con-
tact of connector)
1. Turn starting switch to OFF position.
2. Disconnect PC0 and PL12.
Resistance
Between PC0 (female) (9) and PL12 (female) (1) Max. 1 z
Between PC0 (female) (40) and PLCU (female) (2) Max. 1 z
2
Defective parking brake interlock
relay
1. Turn starting switch to OFF position.
2. Disconnect PL12.
Resistance
Between PL12 (male) (1) and (2) 200 to 400 z
Between ground and each of PL12 (male) (1) and
(2)
Min. 1 Mz
3 Defective power ladder controller
If no failure is found by check on causes 1 and 2, power ladder controller may
be defective. (Since this is an internal defect, troubleshooting cannot be per-
formed.)
40-9
