Method of Usage Method of Usage
X. Pillow Pad and backrest pad's dismounting and use manual
Zipper
Zipper
·The use of the head cushion can reduce the intensity of kneading massage on
the neck and shoulders. You can decide whether to use the head cushion
according to your own needs (the head cushion is recommended). The backrest
and the back cushion are connected by a zipper (1). The head cushion and the
backrest are connected by a zipper (2).
IX. Controller bracket installation instructions
After the screw thread on the support knob of the controller rest assembly aligns to
the screw thread position of the support mounting seat on the armrest of the
massage chair, just turn clockwise and screw tightly for fixation.
VIII. Calf Installation Instruction
·After connecting the wires and the air hose between the legrest and the massage
chair, remove the cable ties and insert the connecting part into the seat (Figure 1).
·Place the round tubes on the left and right sides of the legrest onto the legrest
support (Figure 2).
·Next, turn the legrest fixing cover over to cover the round tubes on both sides of
the legrest (Figure 3).
·Fasten the legrest to the massage chair with two M4 screws (one on each side).
Check whether there is any abnormality during turning up and down, or any tube,
cable or wire is folded. If everything is OK, the legrest is installed (Figure 4).
1 2
3 4
