Konftel 300IP - EP-49 Negative Test: Phone Power Failure; EP-50 Negative Test: Abnormal Call Scenarios

© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public. Page 56 of 64
7101 did not go on-hook when 7100 was disconnected. No SIP message to that
extension. DUTs on PoE
x
Test Case #
EP-49
Category
Negative Test: Phone Power Failure
RFC_Standard
Y
Objective
Verify DUT(s) recovers from a power failure
Pre-Test Conditions
• Local CUCMDUT(s):7100 & 7101;SCCP:1000; SIP:2000;
• Remote CUCMDUT:8000;
• RPC is used to remotely control IP Phones with DN: 1000,2000;
Test Procedure
Expected Results
1. 7100 dials 71017101 answers
2. Remove power cable from 7101
3. Restore power cable after 60s
4. 2000 dials 71017101 answers call
5. 7101 goes on-hook after 60s
6. Retrieve CDR from CUCM
7. Check Calling, Called, Duration, Origination & Termination
Cause Codes
• Call establish between 7100 & 7101 with 2-way audio
• 7101 lost power
• Stable call drops
• Device 7101 re-registers after power is restored
• Network Data: DNS, DHCP, TFTP, CUCM, VLAN, Load ID are
restored on device
• Call establish between 2000 & 7101 with 2-way audio
• Call terminate normally
• 2 CDR(s) retrieved
• Selected fields in CDR(s) match calls
Test Results: Comments
P
F
N/A
N/S
N/T
B
7100 did not go on-hook when 7101 was disconnected. No SIP message to that
extension. DUTs on PoE
x
Test Case #
EP-50
Category
Negative Test: Abnormal Call Scenarios
RFC_Standard
Y
Objective
Verify calls on DUT for negative call scenarios (Invalid DN, Busy DN, Abandoned, RNA)
Pre-Test Conditions
• Local CUCMDUT(s):7100 & 7101;SCCP:1000; SIP:2000;
• Remote CUCMDUT:8000;
• Invalid DN:7777
• Call Waiting disabled for 7100 & 7100
• Device Profile: Busy Trigger set to 1 for DN: 7100 & 7101
• Voicemail disabled for 1000 & 2000;
• RPC is used to remotely control IP Phones with DN: 1000,2000;
Test Procedure
Expected Results
1. 7100 dials 10001000 answers
2. 7101 dials 7100
3. 7101 dials 1000
4. 7101 dials 2000 (RNA)
5. 7101 dials 7777 (Invalid DN)
6. 7101 dials 234-8000
7. 7101 goes on-hook before 8000 answers (Abandoned)
8. 7100 goes on-hook after 120 secs
9. Retrieve CDR from CUCM
10. Check Calling, Called, Duration, Origination & Termination
Cause Codes
• Call establish between 7100 & 1000 with 2-way audio
• 7101 hears busy tone for calls to 7100 & 1000
• 7101 hears ring back timeout for call to 2000
• 7100 hears reorder tone when it dialed invalid DN:7777
• 1 Call terminated normally
• 5 unsuccessful call attempts
• 6 CDR(s) retrieved
• Selected fields in CDR match calls
