Data Processor
Prepation
Index Function Reference page
Initial settings Initial settings Initialization 76
Language mode Language selection 70
Calibration White calibration Entry of calibration values/calibration 86
User calibration Entry of calibration value/calibration 132
Entry of characters for calibration channel name 134
Delete one channel/all channels 139
Display Change Display Change Display
Absolute value display
81
Color difference display
Absolute value/Color difference display
Pass/Caution/Fail display 84
Graph display 83
Color space Color space selection 78
Color difference target Color difference target Target color setting (measurement value entry) 90
color color Target color setting (value entry) 93
Character string entry for color difference target color name
92
Target color selection 102
Delete one target color/all target colors 96
Processing stored data Data list Selection 1 data retrieval 107
Deleting/Undoing the latest data 112
Deleting the Selected data 112
Page retrieval 108
Page print-out 109
Deleting by page/All page 112
Page Update/select page 105
Statistical operation Operation for one page 110
Basic setting Data protection
Average measurement
Illuminant 72
Back light setting Setting
Color space limit
CMC parameter setting 75
Remote mode 128
Print out Print after each measurement
Print color space Print all selected color spaces 72
Buzzer setting Setting
Optional settings Clock Setting 71
Data transfer 126
Multi-calibration 135
Limit value Setting 116
Timer 125
Other settings LCD contrast Setting 69
Function guide
The Data Processor has the following functions available depending on how it is used.
1) All of the following functions can be used when the Measuring Head and the Data Processor are
connected. (See P.57 "Chapter 3 Data Processor).
2) Functions surrounded by in the following table can be used with the Data Processor alone.
• See P.22 "Measuring Head I and II: Function Guide" for details on the functions which can be used
with the Measuring Head alone.
See P.85 "Measurement" for details on color measurement and color difference measurement.
• The Measuring Head requires registration from the optional software to display the user index. (See
P.127.)
