Presentation
LCD INDICATOR STATUS
1. OUTPUT VOLTAGE Shows the output voltage
2. NORMAL Utility power in normal condition.
3. OVERLOAD UPS overload. The buzzer emits continuous alarm for 30
seconds.
4. BATTERY UPS transfer to backup or battery test mode.
The buzzer emits alarm every four seconds.
5. BATTERY CAPACITY Battery capacity indicator
6. POWER SWITCH Power on-off/*Battery test and buzzer on-off
7. CHARGE AREA 7a: AA/AAA Battery Charge; 7b: 9V Battery Charge; 7c:
USB Charge
8. CHARGE INDICATOR AA/AAA Battery charge indicator (4x GREEN); 9V Battery
charge indicator (1x YELLOW); USB Charge (1x RED)
9. OUTPUT SOCKET Connect with load equipment.
10. INPUT PHONE JACK Insert the phone line into the jack.
11. OUTPUT PHONE JACK Connect to the Tel/Fax/Modem by another phone line.
12. RESET CIRCUIT BREAKER Reset circuit breaker power
13. RS232 PORT A connector to monitor the running status of the UPS
(optional).
14. INPUT POWER CORD Connect to the AC power
AA/AAA/9V Battery Charge:
CHARGE INPUT 220 VAC/50 Hz
CHARGE OUTPUT
1.4 VDC/100 mA (AA)
1.4 VDC/100 mA (AAA)
9.0 VDC/25 mA (9V)
CHARGE
TIME
(HOURS)
AA
AAA
9V
9H/600 mA
12H/800 mA
9H/180 mA
USB Charge:
OUTPUT VOLTAGE 5.0+/-0.2 V
OUTPUT CURRENT ≥300 mA
CHARGE TIME Different type battery charge time differ
