Video
Intel ® HD Graphics 4000 or
Intel ® HD Graphics 3000 or
Intel ® HD Graphics 2500 or
Intel ® HD Graphics 2000 or
Intel ® HD Graphics, depending on actual CPU.
Analogue VGA and digital display ports (2x DP) via the Mobile Intel ® Q77 Chipset.
• VGA (analogue panel)
• 2x DP (DisplayPort), comply with DisplayPort 1.2 specification.
• LVDS panel support (optional) up to 24 bit, 2 pixels/clock and 1920x1200.
• HDMI panel support via DP to HDMI Adapter Converter.
• Second VGA panel support via DP to VGA Adapter Converter
• Second DVI panel support via DP to DVI Adapter Converter
• Triple independent pipes for Mirror and/or independent display support
I/O Control
Via ITE IT8516E Embedded Controller and Winbond W83627DHG I/O Controller
(both via LPC Bus interface)
Peripheral
interfaces
• 2x USB 2.0 ports on I/O area
• 4x USB 3.0 ports on I/O area
• 8x USB 2.0 ports on internal pinrows
• 4x Serial ports (RS232) on internal pinrows
• 2x Serial ATA-600 IDE interfaces (blue)
• 4x Serial ATA-300 IDE interfaces (black)
• 1x Serial ATA-300 IDE interfaces (white), shared with mSATA
• RAID 0/1/5/10 support
• mSATA via mSATA connector, shared with SATA (white)
• PS/2 keyboard and mouse ports via pinrow
LAN
Support
• 1x 10/100/1000Mbits/s LAN (ETHER1) using Intel® Lewisville 82579LM Gigabit
PHY connected to Q77 supporting AMT 8.0
• 2x 10/100/1000Mbits/s LAN (ETHER2/ETHER3)using Intel® Hartwell 82574L PCI
Express controllers
• PXE Netboot supported.
• Wake On LAN (WOL) supported
Expansion
Capabilities
• 2x PCI slot(s) (PCI Local Bus Specification Revision 3.0, 33MHz)
• PCI-Express slots:
o 1 slot PCIe x16 Gen3.0
o 1 slot PCIe x4 (in a x16 slot) Gen2 (EFT samples support only PCIe x1)
o 1 slot miniPCI-Express
• SMBus, compatible with ACCES BUS and I2C BUS, (via Feature connector)
• SPI bus routed to SPI connector
• DDC Bus routed to DP connector when DP Adapters are connected
• 5 x digital input, (via Feature connector)
• 13 x GPIOs (General Purpose I/Os), (via Feature connector)
• DAC, ADC, PWM and TIMER (Multiplexed), (via Feature connector)
• WAKE UP / Interrupt Inputs (Multiplexed), (via Feature connector)
• 3 Wire Bus for GPIO Expansion (up to 152 GPIOs), (via Feature connector)
• 8 bit Timer output, (via Feature connector)
System Specification
