KTQ77/Flex Users Guide
KTD-N0848-B Page 63
9 System Resources
9.1 Memory Map
Address (hex)
Size (hex)
Description
0xFF000000
0xFFFFFFFF
1000000
Intel 82802 Firmware Hub
Motherboard resources
0xFEE00000
0xFEEFFFFF
100000
Motherboard resources
0xFED10000
0xFED93FFF
84000
Motherboard resources
0xFED00000
0xFED003FF
400
High Precision Event Timer
0xF8000000
0xFBFFFFFF
400000
Motherboard resources
0xF7E3B000
0xF7E3B00F
10
Intel® Management Engine Interface
0xF7E39000
0xF7E39FFF
1000
Intel® 82579LM Gigabit #1
0xF7E38000
0xF7E383FF
400
Intel® Chipset USB EHCI – 1E2D
0xF7E37000
0xF7E373FF
400
Intel® Chipset USB EHCI – 1E26
0xF7E36000
0xF7E367FF
800
Intel® Chipset 7 port SATA ACHI – 1E02
0xF7E35000
0xF7E350FF
100
Intel® Chipset SMBus Controller – 1E22
0xF7E30000
0xF7E33FFF
4000
High Definition Audio Controller
0xF7E20000
0xF7E2FFFF
10000
Intel USB 3.0 XHCI
0xF7E00000
0xF7E1FFFF
20000
Intel® 82579LM Gigabit #1
0xF7D20000
0xF7D23FFF
4000
Intel 82574L Gigabit #3
0xF7D00000
0xF7DFFFFF
100000
Intel® Chipset PCIe Root port – 1E10
0xF7D00000
0xF7D1FFFF
20000
Intel 82574L Gigabit #3
0xF7C20000
0xF7C23FFF
4000
Intel 82574L Gigabit #2
0xF7C00000
0xF7CFFFFF
100000
Intel® Chipset PCIe Root port – 1E12
0xF7C00000
0xF7C1FFFF
20000
Intel 82574L Gigabit #2
0xF7800000
0xF7BFFFFF
400000
Intel HD Graphics
0xE0000000
0xEFFFFFFF
10000000
Intel HD Graphics
0xDFA00000
0xFEAFFFFF
1F100000
PCI bus
0xDFA00000
0xDFA00FFF
1000
Motherboard resources
0x40004000
0x40004FFF
1000
System board
0x20000000
0x201FFFFF
200000
System board
0xD0000
0xE7FFF
18000
PCI bus
0xA0000
0xBFFFF 20000
Intel HD Graphics
PCI bus
System Resources
