10.2.15 Advanced - Hardware Health Configuration
Aptio Setup Utility – Copyright © 2012 American Megatrends, Inc.
Advanced
Hardware Health Configuration
System Temperature
System Temperature Ext
CPU Temperature
System Fan Speed
System Temperature Ext Type
Fan Cruise Control
Fan Settings
Fan Min limit
Fan Max limit
CPU Fan Speed
Fan Cruise Control
Fan Settings
Fan Min limit
Fan Max limit
Watchdog Function
PC Speaker/Beep
: 30ºC/86ºF
: 24ºC/75ºF
: 49.10ºC/120ºF
: 1543 RPM
[ OneWire @ GPIO16]
[Thermal]
35
0
100
: 1374 RPM
[Thermal]
50
0
100
0
[Enabled]
Disabled = Full speed.
Thermal: does regulate fan
speed according to specified
temperature.
Speed: does regulate according
to specified RPM.
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/- : Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.15.1236. Copyright © 2012 American Megatrends, Inc
