Kontron KTQ77/Flex - Page 16

KTQ77/Flex Users Guide
KTD-N0848-B Page 16
System Specification
Dual Channel DDR3
1067/1333/1600
4 x DIMM
Q77 PCH
PCIe x16 Graphics
Ivy Bridge or
Sandy Bridge
LGA1155
2x DisplayPort
VGA
PCIe x4 Slot
Intel 82574L 10/100/GBe
14x USB
(4x Gen 3.0 / 2.0)
6x SATA
SDVO to LVDS (option)
VIA Codec
SPI
SPI
TPM
Intel Lewisville PHY
Intel 82574L 10/100/GBe
mSATA
PCIe Mini Card
IO controller
W83627DHG-P(T)
IO controller
ITE8516
PCI slot
PCI slot
COM3/4
COM1/2
FAN CPU/SYS
FEATURE
