Low Power Setup results:
DOS Idle, Mean, No external load
Supply
Current draw
Power consumption
+12V
0,37A
3,96W
+12V P4
0,80A
9,60W
+5V
1,22A
6,10W
+3V3
0,25A
0,83W
-12V
< 100mA
5VSB
< 10 mA
Total
20,49W
Windows 7, mean
3DMARK2005 (first scene) & BiT 6
Supply
Current draw
Power consumption
+12V
0,37A
4,44W
+12V P4
1,62A
19,44W
+5V
2,15A
10,75W
+3V3
0,39A
1,29W
-12V
< 100mA
5VSB
< 10 mA
Total
35,92W
S1 Mode, Mean, No external load
Supply
Current draw
Power consumption
+12V
0,30A
3,60W
+12V P4
0,37A
4,44W
+5V
0,85A
4,25W
+3V3
0,28A
0,92W
-12V
< 100mA
5VSB
< 100mA
Total
13,21W
S3 Mode, Mean, No external load
Supply
Current draw
Power consumption
+12V
0
0W
+12V P4
0
0W
+5V
0
0W
+3V3
0
0W
-12V
0
0W
5VSB
< 100mA
<0.5W
Total
<0.5W
S4 Mode, Mean, No external load
Supply
Current draw
Power consumption
+12V
0
0W
+12V P4
0
0W
+5V
0
0W
+3V3
0
0W
-12V
0
0W
5VSB
< 100mA
<0.5W
Total
<0.5W
