Part Number 000012545 4/14 5
Section 2 Installation Instructions
Location of Ice Machine
The location selected for the ice machine must meet the
following criteria. If any of these criteria are not met, select
another location.
• The location must be free of airborne and other
contaminants.
• The air temperature must be at least 35°F (1.6°C), but
must not exceed 110°F (43.4°C).
NOTE: K1350 Minimum air temperature is 40°F (4.4°C).
• Remote air-cooled - The air temperature must be at least
-20°F (-29°C), but must not exceed 120°F (49°C).
• The location must not be near heat-generating (ovens,
dishwashers, etc) equipment or in direct sunlight and
must be protected from weather.
• The location must not obstruct airflow through or
around the ice machine. Refer to the clearance
requirements chart.
These ice machines are intended for use in applications such
as:
• Staff kitchen areas in shops, offices and other work
environments
• Clients in hotels, motels, farmhouses, bed and breakfast
and other residential type environments
• Catering and similar non-retail applications
Clearance Requirements
* There is no minimum clearance required for water-cooled or remote ice
machines. This value is recommended for efficient operation and
servicing only.
** Indicates Preliminary Data
! Warning
Two or more people or a lifting device are required to
lift this appliance.
! Warning
Do not obstruct ice machine vents or openings.
K0250
Self-Contained
Air-Cooled
Self-Contained
Water-Cooled*
Top/Sides 12" (30.5 cm)** N/A
Back 5" (12.7 cm)** N/A
K0350/K0420
K0500/K0600/
K1000/K1350
Self-Contained
Air-Cooled
Water-Cooled
and
Remote*
Top/Sides 8" (20.3 cm)** 8" (20.3 cm)**
Back 5" (12.7 cm)** 5" (12.7 cm)**
K0420
Tropical Rating
50 Hz Only
Self-Contained
Air-Cooled
Water-Cooled*
Top 24" (61.0 cm)** 8" (20.3 cm)**
Sides 12" (30.5 cm)** 8" (20.3 cm)**
Back 5" (12.7 cm)** 5" (12.7 cm)**
K1000
Tropical Rating
50 Hz Only
Self-Contained
Air-Cooled
Water-Cooled
and
Remote*
Top 12" (30.5 cm)** 8" (20.3 cm)**
Sides 8" (20.3 cm)** 8" (20.3 cm)**
Back 5" (12.7 cm)** 5" (12.7 cm)**
!
Caution
The ice machine must be protected if it will be
subjected to temperatures below 32°F (0°C). Failure
caused by exposure to freezing temperatures is not
covered by the warranty.
