Part Number STH063 9/17 149
REMOTE AIR-COOLED CONDENSER
Number Component
1 Compressor
2 Strainer
3 Condenser - Remote Air-Cooled
4 Head Pressure Control Valve
5 Liquid Line Check Valve
6 Receiver
7 Liquid Line Filter Drier
8 Liquid Line Solenoid Valve
9 Heat Exchanger
10 TXV - Thermostatic Expansion Valve
11 Evaporator
12 Strainer
13 Harvest Solenoid Valve
1
2
3
4
5
6
7
8
9
10
11
12
13
15
16
