Fasten BASE with HEX BOLTS (B)
4
CABINET
BOTTOM
FRONT BASE
1
3
4
STEP 3 : HINGE,BASE AND LEGS INSTALLATION
Raise cabinet and check for potential air
leaks at panel joints from inside.
2
Install four LEGS (F)
into BASES fully in.
3
Open Box VP3.
Fasten one HINGE (found in
door box) to the SIDE of the
cabinet with Hexbolts (B).
NOTE :
Fasten BASE to the BOTTOM
of the cabinet (FRONT BASE
has to be set with Base Tabs
Hinge can be on either
side of the cabinet.
1
F
C
B
NOTE: Fasten base with base tab away from the
front edge, then fasten and adjust the hinge
before fully tightening HEX BOLTS (B)
3
F
5
5
B
