INSTALLATION & OPERATION MANUAL

Koolspace Wine Cooling System

100 - 300 - 600 - 900

Table of Contents

Questions and Answers:

S
Sherri MortonJul 30, 2025
Why is my Koolspace chillR 100 Wine Cooler running but not cooling enough?
- C
  Cassandra SpencerJul 31, 2025
  If your Koolspace Wine Cooler runs but doesn't cool sufficiently, it could be due to several factors. First, it may take a few days for the unit to reach the desired storage temperature. Try to reduce ambient temperatures outside the wine room and compensate for any additional heat gain if the walls receive direct sunlight. Also, ensure the door is sealed tightly and that there are no visible gaps; if there are, seal the joints airtight. Improve air circulation to and from the unit as instructed, clean the grill areas, and decrease your set temperature.
J
Joann PooleAug 14, 2025
What to do if my Koolspace Wine Cooler doesn't run when plugged in?
- W
  williamgibsonAug 14, 2025
  If your Koolspace Wine Cooler's cooling unit doesn't start when plugged in, there might be a simple explanation. The unit has a built-in 1-minute cautionary delay to protect the compressor from sudden power failures. Ensure you're using a dedicated, separately fused, and grounded 15 Amp, 120V line. Use an extension cord rated for 15 Amps and avoid sharing the outlet with other appliances. If that doesn't work, unplug the unit, remove the controller, and check the replaceable fuse (0.5A SLOW BLOW, 250V, 5X20mm) in the controller. Alternatively, try unplugging the unit for ten minutes, then plugging it back in.

Koolspace chillR 100 Specifications

General

Brand	Koolspace
Model	chillR 100
Category	Wine Cooler
Language	English

Summary

READ BEFORE YOU START

Electrical and Power Safety

STEP 1: INSTALLING COOLING UNIT

Unit Placement and Securing

Instructions for inserting the cooling unit through the cutout and securing it to the wall studs.

STEP 2: INSTALLING REAR FRAME AND DRAIN PAN

Securing the Rear Frame

Instructions for attaching the rear frame to the wall studs using provided screws.

Drain Pan Installation and Sealing

Guidance on installing the drain pan correctly and ensuring a good seal around the unit.

Power Connection and Cord Management

CONTROLS: PLUG IT IN

Unit Features and Operation

Temperature Adjustment and Calibration

Safety Features: Alarm and Overflow

Explanation of the unit's alarm system for high temperatures and overflow warnings.

TROUBLE SHOOTING GUIDE

Unit Not Running Troubleshooting

Diagnosing issues when the cooling unit does not power on or fans are not running.

Cooling Performance Issues

Troubleshooting steps for when the unit runs but does not cool sufficiently.

LIMITED WARRANTY AND PRODUCT SUPPORT

Three Year Limited Warranty Terms

Details of the warranty coverage, duration, and limitations for the cooling unit.

Warranty Claim and Service Procedures

How to register the warranty, make a claim, and request repair or replacement.

Warranty Exclusions and Responsibilities
