Electrical Control Function
caused by Tp.
Bit1
Frequency limit
caused by current
Bit0
Frequency limit
caused by voltage
16 DC fan motor speed
17 IGBT radiator temp.(Reserved)
The display value is between 13~120 degree. If the temp. is
lower than 13 degree, the digital display tube will show “13”.If
the temp. is higher than 99 degree, the digital display tube will
show single digit and tens digit. (For example, the digital
display tube show “0.5”,it means the IGBT radiator temp. is
105 degree. the digital display tube show “1.6”,it means the
IGBT radiator temp. is 116 degree)
For KV48ODU-ARF21B & KV60ODU-CRF21
: The display
value is between 30~120 degree. If the temp. is low
er than
30 degree, the digital display tube will show “30”.If the temp.
is higher than 99 degree,
18
Indoor unit number The indoor unit can communicate with outdoor unit well.
19
Condenser pipe temp. of 1# indoor unit If the temp. is lower than 0 degree, the digital display tube will
show “0”.If the temp. is higher than 70 degree, the digital
display tube will show “70”. If the capacity demand is 0, , the
digital display tube will show “0. If the indoor unit is not
connected, the digital display tube will show: “――”
20 Condenser pipe temp. of 2# indoor unit
21 Condenser pipe temp. of 3# indoor unit
22 1# Indoor unit capacity demand code
Actual data*HP*10
If capacity demand code is higher than 99, the digital display
tube will show single digit and tens digit. (For example, the
digital display tube show “5.0”,it means the capacity demand
is 15. the digital display tube show “60”,it means the capacity
demand is 6.0). If the indoor unit is not connected, the digital
display tube will show: “――”
23 2# Indoor unit capacity demand code
24 3# Indoor unit capacity demand code
