Korg KingKORG Service Manual

The main display is displayed as shown in the pictur e
shown to the r ight.
Check t he vol tage with a digi tal mul ti met er.
The foll owing tabl e shows the st andar d vol tage.
Lower li mit Refer ence value Upper limit Unit
0.990 1.000 1.010 V
Aft er confir ming, pr ess the [VALU E di al], pr oceed t o t he next inspection
Connect to the GATE ter minal of the mult imeter to V of CV/GATE testing cable.
The main display is displ ayed as shown in the pict ur e
shown to the r ight.
Check t he vol tage with a digi tal mul ti met er.
The foll owing tabl e shows the st andar d vol tage.
Lower li mit Refer ence value Upper limit Unit
0.000 0.000 0.500 V
Aft er confir ming, pr ess the [VALU E di al], pr oceed t o t he next inspection.
The main displ ay is displ ayed as shown in t he pict ur e
shown to the r ight.
Check t he vol tage with a digi tal
mult imet er.
The foll owing tabl e shows the st andar d vol tage.
Lower li mit Refer ence value Upper limit Unit
4.500 5.000 5.500 V
Aft er confir ming, pr ess the [VALU E di al], pr oceed t o t he next inspection
Connect to the GATE ter minal of the mult imeter to V of CV/GATE testing cable.
4. L ED and displ ay check
4-1. Di splay and L ED all l ight s check
The main di splay and the L ED will il luminat e all as shown in the phot o below and next page.
