Quick settings
1. Start out by making the following settings.
VOLUME knob: center TONE: center
POWER SAG knob: MIN (counterclockwise) SUSTAIN: MIN
MIX knob: TUBE THRESHOLD: MIN
GAIN knob: in the 9 o’clock position
Adjust the VOLUME knob so that the level of the effected sound is
about the same as the bypassed sound (when the effect is off).
2. While playing the guitar, turn the POWER SAG knob to increase the
sag until the Nutube goes dark at the moment that you play.
If the Nutube stays lit even at the maximum setting, turn the
THRESHOLD to adjust the level.
3. Check how the compression sounds when the sag is increased.
For single-coil: the effect increases as you turn the THRESHOLD
clockwise.
For humbucking coils: turn the THRESHOLD counterclockwise to
adjust.
4. If the compression is too strong, adjust by turning the knob to the
DIRECT side to mix the direct sound.
When you mix in the direct sound with a large amount of SUSTAIN,
you can get a sound with an attack but also a long sustain.
5. Use TONE to adjust the attack feel.
We recommend that you set this to a position slightly left of center
(around the 11 o’clock position).
Part Names and Functions
2
1
7
8
3
1. VOLUME knob: Adjusts the volume.
2. POWER SAG knob: Adjusts the simulated “sag,” meaning the
compression sound created by power tubes.
3. MIX knob:
Adjusts the mix volumes of the direct sound and the Nutube sound.
4. TUBE GAIN knob: Adjusts the vacuum tube input level.
5. EFFECT ON/OFF switch: Switches the effector on/off.
6. EFFECT ON/OFF LED: The indicator lights when the effector is on.
7. Adjustable half-fixed volume screws: Use tool [E] to adjust these.
TONE: Adjusts the attack feel.
SUSTAIN: Adjusts the sag sustain time.
THRESHOLD:
Adjusts the level at which the sag effect begins to be applied.
8. Window: Use this to check how the Nutube is lighting up.
To adjust the adjustable half-fixed volume screws (TONE, SUSTAIN,
THRESHOLD), use the special adjustment screwdriver that’s
included in the tool and pick set.
When using a metal screwdriver or similar tool, the Nutube lighting
may change or blink. if the metallic part of the screwdriver touches
the frame of the case while you’re making adjustments.
