FV = FULL VIEW D = Pa80 DISASSEMBLY LD1 = LOWER CASE DISASSEMBLY 1 LD1 = LOWER CASE DISASSEMBLY 2
UD1 = UPPER CASE DISASSEMBLY 1 UD2 = UPPER CASE DISASSEMBLY 2 UD3 = UPPER CASE DISASSEMBLY 3
UD4 = UPPER CASE DISASSEMBLY 4 PA = POWER AMPLIFIER PSS = POWER SWITCHING SUPPLY
MB = MAIN BOARD GROUP FD = FLOPPY DISK GROUP OB = OUTPUT BOARD
PART LIST OUTPUT BOARD KIP-2028
CODE PART-TYPE REFERENCE QTY
BOB0005002 EMI FERRITE BLM21B102SPT L1-6 6
CIN0001008 I.C. INVERTER O.C. 74HC05 IC3 1
CIN0001011 DUAL TRANSCEIVER M5M34050P IC6 1
CIN0001012 I.C. PC-910K PH.COUPLER IC1 1
CIN0001016 I.C. 74HC4052 MUX/DEMUX IC8 IC11-12 3
CIN0001017 I.C. MJM4580D DUAL LOWNOISE OP.A IC2 IC4-5 IC7 IC9-10 6
DIX0005300 SIGNAL DIODE 1 N 4148 D1-19 19
DIX0005301 ZENER DIODE VZ 4.7 V DZ1-2 2
POT0001005 ROT. POTENT. C.L.10KC H 6.5 OR VR1-2 2
TRS0001001 NPN DIGITAL TRANSISTOR Q6-9 4
TRS0001008 NPN BIPOL. TRASISTOR 2SD2144S Q1-4 4
PART LIST DIGITAL AMPLIFIER KIP-2030
CODE PART-TYPE REFERENCE QTY
BOB0001004 COIL 10uH TSL0809RA-100K2R2 LC1-4 4
BOB0005001 COIL VK200 2,0 SPIRE L1 1
CIN0001003 GRAFIC EQUALIZER M5243AP09 IC3 1
CIN0002042 I.C. STEREO LOUDNESS BA3570F-E2 IC6 1
DIX0005002 RECTIFIER DIODE 1N 4002 D6-7 2
DIX0005004 SHOTTLY DIODE 1N5819 40V D2-5 4
DIX0005300 SIGNAL DIODE 1 N 4148 D1 D8 2
DIX0005301 ZENER DIODE VZ 4.7 V D10 1
FER0001089 I.C. HOLDER POWER AMPLI. PA 1
FER0001096 AMPLIFIER HEATSINK PA 1
FER0001107 RECTIFIER HEATSINK 7141D X6 1
TRS0001002 PNP DIGITAL TRANSISTOR Q1 1
TRS0001010 POS. REG. 1A +8 7808 IC5 1
TRS0001011 NEG. REG. 1A -8 7908 IC4 1
TRS0001012 DIGITAL AMPLIFIER TA2020-020 IC1 1
TRS0005002 PNP TRANSISTOR BC 558 Q2 1
PART LIST HEADPHONE BOARD KIP-2031
CODE PART-TYPE REFERENCE QTY
BOB0005002 EMI FERRITE BLM21B102SPT L1-2 2
CIN0001009 DUAL HEADPH. OP.M5216P U1 1
TRS0001008 NPL BIPOLAR TRASISTOR 2SD2144S Q1-2 2
PART LIST ROTARY ENCODER KIP-2034
CODE PART-TYPE REFERENCE QTY
INT0001006 INCREMENTAL ENCODER RE1 1
