Korg PA80 Abridged Service Manual

2
3D6SHFLILFDWLRQV
.H\ERDUG
61 notes with velocity and after touch
6\VWHP
OPOS – Objective Portable Operating System: Multitasking System, load while
playing feature. Upgradable Operating System. SSD Solid State Disk.
7RQHJHQHUDWRU
HI synthesis (Hyper integrated synthesis system) – 62 voices, 62 oscillators –
Filters with resonance.
:DYHIRUP0HPRU\
32 Mbyte PCM ROM (Stereo Piano Sound).
(IIHFWV
4 stereo digital Multi-Effect systems (90 effects each).
3URJUDPV
More than 660 programs (including Stereo Piano and GM level 2 programs ).
32 drum kits. 128 user programs + 32 user drum kits – Digital Organ drawbars.
6W\OHV
More than 200 Styles in Solid State Disk. All reconfigurable – 8 accompaniment
tracks. 48 user styles. All Style Performances are programmable (included 4
Single Touch Settings for each style). Direct Disk/Direct Hard Disk feature.
Compatible with old i series style format.
6W\OHV&RQWUROV
4 Variations, 2 Fills, 2 Intros, 2 Endings, Counter In/Break, Synchro Start/Stop,
Tap Tempo/Reset, Fade In/Out, Bass Inversion, Manual Bass, Tempo Lock,
Memory, Accompaniment Volume, Accompaniment Mute, Drum Mapping,
Snare & Kick Designation, Single Touch.
*HQHUDO&RQWUROV
Master Volume, Ensemble, Octave Transpose, Master Transpose, Split Point,
Style Change, Tracks Volume, Quarter of tone Pedal Function, Programmable
Slider, Joystick, Dial.
0XOWL3$'
4 assignable pads + Stop button.
3HUIRUPDQFH
80 real-time Performances + more than 200 Styles Performances (that
contains 4 Single Touch Settings each)
6RQJ3OD\
XDS* Crossfade Dual Sequencer player – 2 Sequencers with separate
Start/Stop, Pause, ‘<< Rew’ and ‘>> FF’ controls. Balance control. Lyrics are
displayed on-screen. Jukebox Function. SMF Direct Player (format 0 and 1).
6RQJ%DFNLQJ
6HTXHQFH
Easy record – 16 tracks – SMF format.
&RQWURO,QSXWV
Damper Pedal, Assignable pedal/switch, EC5 (programmable multiswitches).
$XGLR2XWSXWV
Left/mono, Right – Out 1 – Out 2.
$XGLR,QSXWV
Left/mono, Right, with separate Gain controls (Mic, Guitar, Line).
0,',
In, Out, Thru, PC to Host.
)ORSS\'LVN
3.5 inch 2DD/2HD (MS-DOS compatible).
'LVSOD\
Backlit custom LCD.
0DLQ$PSOLILHU
2x22 Watt.
6SHDNHUV
4 speakers (in Bass Reflex Box- Auto Loudness control).
3RZHU&RQVXPSWLRQ
35 Watt.
'LPHQVLRQV
W = 1110mm, D = 388mm, H = 164mm without music rest.
:HLJKW
13.9 kg.
$FFHVVRULHV
EC5 Multi-switches controller, EXP-2 Foot Controller, XVP-10 Exp/Volume
Pedal, PS-1 Footswitch, DS-1H Damper Pedal.
2SWLRQ
Flash Card (PCMCIA) for new PCM data – Vocal/Guitar processor board –
Hard Disk (up to 2 Gbyte ) – Optional Video Interface board.
 6SHFLILFDWLRQ DQG GHVLJQ DUH VXEMHFW WR FKDQJH ZLWKRXW QRWLFH IRU WKH SXUSRVH RI SURGXFW
HQKDQFHPHQW

Korg PA80 Specifications

General

Polyphony	62 voices
ROM	32 MB
MIDI	In, Out, Thru
Inputs	Mic/Line input
Keyboard	61 keys
Effects	4 stereo digital multi-effect systems
Sequencer	16-track sequencer
Display	Backlit LCD
Storage	3.5" HD floppy disk drive
Sound Engine	HI Synthesis (Hyper Integrated)
Styles	Over 300 Styles preloaded in Solid State Disk
Outputs	L/Mono, R, Headphones
Connections	MIDI
Power Supply	AC power supply
