MIDI Implementation Chart
To obtain the TRINITY V3, V3 pro or V3 proX “MIDI Implementation,” please contact a Korg distributor.
Function Transmitted Recognized Remarks
Basic Channel
Default 1 – 16 1–16 Memorized
Changed 1 – 16 1–16
Mode
Default 3
Messages X X
Altered **********************
Note
Number:
24–108/16–115/9–120
0–127
(Transmission) TRINITY, V3, plus / V3pro, pro / V3proX, proX
True Voice ********************** 0–127 When sequencer data is sent: 0 – 127
Velocity
Note On O 9n, V=1 – 127 O 9n, V=1 – 127
Note Off X X
Aftertouch
Polyphonic (Key) O O
Only sequencer data is transmitted for each key
*A
Monophonic
(Channel)
OO *A
Pitch Bend O O *C
Control
Change
0, 32 O O Bank Select (MSB, LSB) *P
1, 2, 16, 17, 18 O O Joystick (+Y, –Y), Ribboon (X, Z), Slider *C
4, 64, 82 O O Footpedal, Sustain pedal, Footpedal *C
6, 38, 96, 97 X O
Data Entry (MSB, LSB), Increment, decrement
*E
7, 11 O O Volume, Expression *C
10, 91, 93 O O L:R panpot, Send 2, 1 *C
12, 13, 80, 81 O O Effect controller 1, 2, Panel switch 1, 2 *C
19, 72, 73, 74, 83 X O
EG time (Release, Attack), Brightness,
Controller *C
92 ,94, 95 O O Insert, Master (M, R/D), Effect on/off *C
100, 101 X O RPN (LSB, MSB) *2
120, 121 X O All sound off, Reset all Controllers
5, 65 X, O O Portamento Control (onnly for solo synth) *C
0 – 101 O O (Sequencer data)
Program
Change
O 0 – 127 O 0 – 127 *P
Variable Range
********************** 0 – 127 0–63 for solo synthesizer
System Exclusive O O *3 *E
System
Common
Song Position O O *1
Song Select O 0 – 9 O 0 – 9*1
Tune X X
System
Real Time
Clock O O *1
Command O O *1
Aux
Messages
Local On/Off X O
All Notes Off X O 123 – 127
Active Sense O O
Reset X X
Notes
*C, *P, *A, *E: Sent and received when MIDI Filter (Controller, Program Change, Aftertouch, System Exclusive) is
set to ENA.
*1: When clock is set to internal, sent but not received. When set to external, received but not sent.
*2: LSB, MSB = 00,00: pitch bend range, =01,00: fine tune, =02,00: course tune
*3: Includes Inquiry, Master Balance, and Master Volume messages.
Mode 1:OMNI ON, POLY
Mode 3:OMNI OFF, POLY
Mode 2:OMNI ON, MONO
Mode 4:OMNI OFF, MONO
O: Yes
X: No
