Korg TRITON Le Service Manual

PART CODE PART NAME NOTE
Q
'TY
324021114
IC SN74LV05APWR
(
TS
)
KLM-2277 TRITO 1
324021119
IC SN74LV4051APWR
(
TS
)
KLM-2277 TRITO 1
324021122
IC SN74LV139ANSR
(
TS
)
KLM-2277 TRITO 1
324021123
IC SN74LV125ANSR
(
TS
)
KLM-2277 TRITO 1
324023007
IC S-8520F50MC-B0J-T2
(
TS
)
KLM-2277 TRITO 1
324024001
IC L1087MPX-ADJ
(
TS
)
KLM-2277 TRITO 1
324027011
IC GM71C18163CJ-6
(
T
)
(
TS
)
KLM-2277 TRITO 3
324036008
IC PCM1716E/2K
(
TS
)
KLM-2277 TRITO 2
324045003
IC 93LC66BT-I/SN
(
X16 TYPE
)(
TS KLM-2277 TRITO 1
334000600
PHOTO COUPLER PC-410K
(
TS
)
KLM-2277 TRITO 1
335011900
CRYSTAL OSC CA-301 24.576MHZ KLM-2277 TRITO 1
335012400
CRYSTAL OSC CA-301 8MHZ KLM-2277 TRITO 1
335400140
CERAMIC OSC CSTCC8M00G53-R0
(
TS KLM-2330 TRITO 1
350002233
SFR RH0615CN3J 3.3K KLM-1864 TRITO 1
350002447
SFR RH0615CS5J 470K KLM-1864 TRITO 1
362009007
VR RK11K1140A9L KLM-2278/79/80 4
365009500
SLIDE VR EWA NA0C10B14 10KB KLM-2278/79/80 1
370005000
REC EC11B15204A5 KLM-2278/79/80 1
374000600
TSW EVQ11A09K
(
TR
)
KLM-2278/79/80 54
375014800
PSW SDKLA10200 KLM-2277 TRITO 1
402002800
COIL 2943-666671 KLM-2278/79/80 2
402004600
COIL 2943-666673 KLM-2277 TRITO 3
402006500
COIL TC-600M-3A-5026 KLM-2277 TRITO 1
402007400
AIR COIL SC-0.5X10X16.5TX4R KLM-2277 TRITO 1
404001050
CHIP INDUCTOR BLM21PG600SN1D KLM-2277 TRITO 2
404001070
CHIP INDUCTOR BLM18BD102SN1D KLM-2330 TRITO 6
404001070
CHIP INDUCTOR BLM18BD102SN1D KLM-2277 TRITO 46
405011500
AC-AC ADAPTOR KA161
(
100V/3.0A TRITON LE61 JP 1
405011600
AC-AC ADAPTOR KA163
(
120V/3.0A TRITON LE61 US 1
405011600
AC-AC ADAPTOR KA163
(
120V/3.0A TRITON LE61 EX 1
405011600
AC-AC ADAPTOR KA163
(
120V/3.0A TRITON LE61 CN 1
405011700
AC-AC ADAPTOR KA169
(
230V/3.0A TRITON LE61 WG 1
405011700
AC-AC ADAPTOR KA169
(
230V/3.0A TRITON LE61 GE 1
405011700
AC-AC ADAPTOR KA169
(
230V/3.0A TRITON LE61 FR 1
405011700
AC-AC ADAPTOR KA169
(
230V/3.0A TRITON LE61 UK 1
405011800
AC-AC ADAPTOR KA165
(
240V/3.0A TRITON LE61 AU 1
420005800
61TP/9S+PCBOARD+AFTERTOUCH TRITON LE61 M. 1
450003100
PHONE JACK LGR4609-7000 KLM-2278/79/80 1
454004300
PHONE JACK YKB21-5012 KLM-2277 TRITO 4
454009900
PHONE JACK YKB21-5074G KLM-2277 TRITO 3
454011700
DIN CONNECTOR TCS5073-24-4151 KLM-2277 TRITO 1
464002300
FUSE 125V 2A SB2 TRITON LE61 M. 1
471070301
CONNECTOR TOP B3B-PH-K-S
(
U
)
KLM-1864 TRITO 1
471101030
CONNECTOR TOP SC25-03WS KLM-2277 TRITO 1
471101060
CONNECTOR TOP SC25-06WS KLM-2277 TRITO 1
471101060
CONNECTOR TOP SC25-06WS KLM-2278/79/80 1
471102030
CONNECTOR TOP SJ20-03WX KLM-2278/79/80 1
471102030
CONNECTOR TOP SJ20-03WX KLM-2277 TRITO 1
471102060
CONNECTOR TOP SJ20-06WX KLM-2277 TRITO 1
471102080
CONNECTOR TOP SJ20-08WX KLM-2278/79/80 2
471102080
CONNECTOR TOP SJ20-08WX KLM-2277 TRITO 1

Korg TRITON Le Specifications

General

Polyphony	62 voices
Display	240 x 64 pixel backlit LCD
MIDI	In, Out, Thru
Power Supply	AC adapter (included)
Type	Workstation Keyboard
Keyboard	61 keys
Sound Engine	HI Synthesis
Synthesis Method	PCM
ROM Wave Memory	32 MB
Programs	512 Programs
Drum Kits	24 drum kits
Effects	2 multi-effects processors, 1 master effect, 1 total effect
Sequencer	16-track, 200, 000 notes
Arpeggiator	1 arpeggiator
Storage	SmartMedia card
Outputs	L/MONO, R, Headphones
Floppy Disk Drive	3.5 inch 2DD/2HD
